Acura MDX III facelift 2 (2016-2021) phase motor current sensor Wiring diagram
This page shows the only wiring diagram for the component.phase motor current sensor, which is found in the car Acura MDX III facelift 2 (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram phase motor current sensor (1 of 1)
33-PIN CONNECTOR
ACTIVE DISCHARGE DRIVER
BLK WIRE
BLU WIRE
BRN WIRE
DC-DC CONVERTER
ELECTRIC A/C COMPRESSOR
FRONT MOTOR ECU
GATE DRIVER BOARD
GRN WIRE
GRY WIRE
HIGH VOLTAGE
LEFT SIDE TWIN MOTOR CONNECTOR
LT BLU WIRE
MOTOR CONNECTOR
MPI CONNECTOR
NCA WIRE
PCU SIDE MOTOR CONNECTOR
PHASE MOTOR CURRENT SENSOR
PNK WIRE
PPL
RED WIRE
RIGHT SIDE TWIN MOTOR CONNECTOR
TWIN MOTOR ECU PCU
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.0l hybrid, hybrid system circuit (8 of 8) -> PHASE MOTOR CURRENT SENSOR
