Acura MDX III facelift 2 (2016-2021) (or red/ Wiring diagrams
This page contains all the electrical diagrams for the component. (or red/, in which he is found in the car Acura MDX III facelift 2 (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram (or red/ (1 of 15)
AUXILIARY UNDER-DASH FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER
DRIVER'S UNDER-DASH FUSE/RELAY BOX
FUSE 1
FUSE 11
FUSE 2-6
FUSE 2-7
FUSE 2-8
FUSE 23
FUSE 4
FUSE 7
FUSE 8
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT W/ DC-DC CONVERTER
LEFT FRONT WHEEL SPEED SENSOR
LEFT REAR WHEEL SPEED SENSOR
LT BLU WIRE
MAIN UNDER- HOOD FUSE BOX
MICU
PNK WIRE
PPL
RED WIRE
RIGHT FRONT WHEEL SPEED SENSOR
RIGHT REAR WHEEL SPEED SENSOR
TAN WIRE
VSA MODULATOR CONTROL UNIT
W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit, except hybrid (1 of 2) -> (OR RED/ WIRE
Wiring diagram (or red/ (2 of 15)
32-BIT MICROCOMPUTER + FLASH ROM
ABS IND.
BLK WIRE
BLU WIRE
BRAKE IND
BRAKE PEDAL POSITION SWITCH
BRAKE SYSTEM IND
BRN WIRE
CIRCUIT
CMBS OFF SWITCH
CMBS/FCW IND
COMPULSORY
COMPUTER DATA LINES SYSTEM
EPS CONTROL UNIT
F-CAN
F-CAN H
F-CAN L
FAIL-SAFE
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEATED WINDSHIELD WIPER AREA/ CMBS OFF SWITCH
KEYLESS ACCESS/TPMS CONTROL UNIT
MULTI INFORMATION DISPLAY (TFT)
PCM
PNK WIRE
PPL
RDM/LDW/ VSA OFF SWITCH
RED WIRE
STEERING ANGLE SENSOR
TAN WIRE
TRANSCEIVER/
TURNING-ON
VSA IND
VSA OFF IND
VSA OFF SWITCH
W/ AUTO IDLE STOP SYSTEM 5 PIN CONNECTOR 12 PIN CONNECTOR
WARNING DRIVER CIRCUIT
WHT WIRE
Go to component -> Anti-lock brakes circuit, except hybrid (2 of 2) -> (OR RED/ WIRE
Wiring diagram (or red/ (3 of 15)
A/C CONDENSER FAN RELAY
A/C DIODE A
A/C DIODE B
BLK WIRE
BLU WIRE
BRN WIRE
CLIMATE CONTROL UNIT
DIODE C
DRIVER'S AIR MIX CONTROL MOTOR
ELECTRIC HEATER COOLANT PUMP RELAY
EXCEPT HYBRID
FRONT MODE CONTROL MOTOR
FUSE 17
FUSE 28
FUSE 29
FUSE 30
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ PGM-FI MAIN RELAY 1 ENERGIZED
LT BLU WIRE
LT GRN WIRE
MODE CONTROL MOTOR A
PNK WIRE
PPL
RADIATOR FAN RELAY
REAR AIR MIX CONTROL MOTOR
REAR MODE CONTROL MOTOR
REAR WINDOW DEFOGGER RELAY
RED WIRE
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
W/ AUTO IDLE STOP SYSTEM W/O AUTO IDLE STOP SYSTEM EXCEPT HYBRID HYBRID
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (1 of 5) -> (OR RED/ WIRE
Wiring diagram (or red/ (4 of 15)
32 BIT MICROPROCESSOR, FLASH ROM
32-BIT MICROCOMPUTER + FLASH ROM
AUXILIARY UNDER-DASH FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRN WIRE
CIRCUIT
COMPULSORY TURNING- OFF CIRCUIT
COMPULSORY TURNING- ON CIRCUIT
COMPUTER DATA LINES SYSTEM
DRIVER'S UNDER-DASH FUSE/RELAY BOX
EPS CONTROL UNIT
EPS IND
EPS MOTOR
EPS MOTOR ANGLE SENSOR
EXCEPT HYBRID
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FAIL SAFE CIRCUIT
FUSE 11
FUSE 2-1
FUSE 23
FUSE 3-5
FUSE 4
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ DC-DC
LT BLU WIRE
MAIN UNDER- HOOD FUSE BOX
MICU
MULTI INFORMATION DISPLAY (TFT)
MULTI-PURPOSE CAMERA UNIT
PCM (EXCEPT HYBRID)
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
STEERING ANGLE SENSOR
STEERING GEAR BOX
TORQUE SENSOR
W/ AUTO IDLE STOP SYSTEM W/O AUTO IDLE STOP SYSTEM EXCEPT HYBRID HYBRID
WARNING
WHT WIRE
YEL WIRE
Go to component -> Electronic power steering circuit -> (OR RED/ WIRE
Wiring diagram (or red/ (5 of 15)
AUDIO UNIT/AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S JUNCTION BOX A
FUSE 16
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LIN I/F
LJOG
LT BLU WIRE
MCU
NAVIGATION SYSTEM
NCA WIRE
OFF HOOK
ON HOOK/ BACK
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
PUSH TALK
REAR CAMERA CIRCUIT
REAR CAMERA CIRCUITS)
REAR SEAT ENTERTAINMENT CIRCUIT
RED WIRE
REGULATOR
REW
SIG GND
SOUND SYSTEMS
SOURCE
STEERING COMMANDER SWITCH ASSEMBLY
STRG GND
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, except hybrid (7 of 9) -> (OR RED/ WIRE
Wiring diagram (or red/ (6 of 15)
ACC COMBINATION SWITCH
AUDIO REMOTE SWITCH/HFT-NAVIGATION VOICE CONTROL SWITCH
AUDIO- NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
DISP SWITCH
DRIVER'S JUNCTION BOX A
FUSE 16
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
NAVIGATION SYSTEM
NCA WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
PUSH SWITCH
REAR CAMERA CIRCUIT
REAR CAMERA CIRCUITS)
REAR SEAT ENTERTAINMENT CIRCUIT
RED WIRE
SEATS SYSTEM
SOUND SYSTEMS
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, hybrid (7 of 9) -> (OR RED/ WIRE
Wiring diagram (or red/ (7 of 15)
A/C COMPRESSOR CLUTCH RELAY
A/C CONDENSER FAN RELAY
ALTERNATOR
AUXILIARY UNDER-DASH RELAY BLOCK A
AUXILIARY UNDER-DASH RELAY BLOCK B
BATTERY
BATTERY FAN MOTOR
BATTERY SENSOR
BATTERY TERMINAL FUSE BOX
BLK WIRE
BLU WIRE
BRAKE LIGHT RELAY
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CABLE REEL
DRIVER'S JUNCTION BOX B
DRIVER'S UNDER-DASH FUSE/RELAY BOX
EPS CONTROL UNIT
FROM MAIN UNDER-HOOD FUSE BOX (DIAGRAM 2 OF 10)
FROM MAIN UNDER-HOOD FUSE BOX (DIAGRAM 9 OF 10)
FRONT FOG LIGHT RELAY
FUSE 1
FUSE 10
FUSE 17
FUSE 18
FUSE 2-1
FUSE 2-2
FUSE 2-3
FUSE 2-4
FUSE 2-5
FUSE 2-6
FUSE 2-7
FUSE 2-8
FUSE 29
FUSE 30
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
HORN RELAY
LEFT HEADLIGHT
LT BLU WIRE
MAIN UNDER- HOOD FUSE BOX
MICU
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
POWER TAILGATE CONTROL UNIT
POWER TILT/ TELESCOPE STEERING CONTROL UNIT
RADIATOR FAN RELAY
REAR BLOWER MOTOR RELAY
REAR FUSE/ RELAY BOX
RED WIRE
RIGHT HEADLIGHT
STARTER
STEERING COLUMN)
STEERING COMMANDER SWITCH ASSEMBLY
TAN WIRE
TO AUXILIARY UNDER-DASH FUSE BOX (DIAGRAM 9 OF 10)
TO FUSE 7 (DIAGRAM 2 OF 10)
TO PASSENGER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 4 OF 10)
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (1 of 10) -> (OR RED/ WIRE
Wiring diagram (or red/ (8 of 15)
AUDIO UNIT/AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S JUNCTION BOX A
FUSE 16
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LIN I/F
LJOG
LT BLU WIRE
MCU
NAVIGATION SYSTEM
NCA WIRE
OFF HOOK
ON HOOK/ BACK
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
PUSH TALK
REAR CAMERA CIRCUIT
REAR CAMERA CIRCUITS)
REAR SEAT ENTERTAINMENT CIRCUIT
RED WIRE
REGULATOR
REW
SIG GND
SOUND SYSTEMS
SOURCE
STEERING COMMANDER SWITCH ASSEMBLY
STRG GND
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, except hybrid w/ navigation (7 of 9) -> (OR RED/ WIRE
Wiring diagram (or red/ (9 of 15)
ACC COMBINATION SWITCH
AUDIO REMOTE SWITCH/HFT-NAVIGATION VOICE CONTROL SWITCH
AUDIO- NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
DISP SWITCH
DRIVER'S JUNCTION BOX A
FUSE 16
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
NAVIGATION SYSTEM
NCA WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
PUSH SWITCH
REAR CAMERA CIRCUIT
REAR CAMERA CIRCUITS)
REAR SEAT ENTERTAINMENT CIRCUIT
RED WIRE
SEATS SYSTEM
SOUND SYSTEMS
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, hybrid (7 of 9) -> (OR RED/ WIRE
Wiring diagram (or red/ (10 of 15)
APP SENSOR
APP SENSOR A
APP SENSOR B
AUXILIARY UNDER-DASH FUSE BOX
BLK WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CENTER JUNCTION BOX
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER
DRIVER'S UNDER-DASH FUSE/RELAY BOX
FUSE 11
FUSE 2-6
FUSE 25
FUSE 3
FUSE 8
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
LT BLU WIRE
MAIN UNDER- HOOD FUSE BOX
PCM
PNK WIRE
PPL
RED WIRE
SBW SHIFTER CONTROL MODULE
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit, except hybrid -> (OR RED/ WIRE
