Acura MDX III facelift 2 (2016-2021) left side curtain air bag inflator Wiring diagram
This page shows the only wiring diagram for the component.left side curtain air bag inflator, which is found in the car Acura MDX III facelift 2 (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left side curtain air bag inflator (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT POSITION SENSOR
DRIVER'S SIDE AIR BAG INFLATOR
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SIDE AIR BAG INFLATOR
GRN WIRE
GRY WIRE
HYBRID EXCEPT HYBRID
LEFT SIDE CURTAIN AIR BAG INFLATOR
LEFT SIDE IMPACT SENSOR (FIRST)
LEFT SIDE IMPACT SENSOR (SECOND)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
REAR SAFING SENSOR
RED WIRE
RIGHT SIDE CURTAIN AIR BAG INFLATOR
RIGHT SIDE IMPACT SENSOR (FIRST)
RIGHT SIDE IMPACT SENSOR (SECOND)
SRS UNIT
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> LEFT SIDE CURTAIN AIR BAG INFLATOR
