Acura MDX III facelift 2 (2016-2021) electrical compass unit Wiring diagrams
This page contains all the electrical diagrams for the component. electrical compass unit, in which he is found in the car Acura MDX III facelift 2 (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram electrical compass unit (1 of 3)
Go to component -> Compass circuit -> ELECTRICAL COMPASS UNIT
Wiring diagram electrical compass unit (2 of 3)
AUDIO UNIT/ AUDIO NAVIGATION UNIT
AUTOMATIC DIMMING INSIDE MIRROR
AUTOMATIC LIGHTING/ RAIN SENSOR
BLK WIRE
CABLE REEL
CARPLAY, ANDROID AUTO UNIT
CONNECTOR
CONSOLE ACCESSORY POWER SOCKET
DATA LINK CONNECTOR (DLC)
DRIVER'S DOOR POWER TAILGATE/ FUEL FILL DOOR OPENER SWITCH
DRIVER'S POWER WINDOW MASTER SWITCH
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVER'S VANITY MIRROR LIGHT
DVD PLAYER UNIT
ELECTRICAL COMPASS UNIT
FRONT ACCESSORY POWER SOCKET
FRONT PASSENGER'S POWER WINDOW SWITCH
GAUGE CONTROL MODULE
HEATED WINDSHIELD WIPER AREA/ CMBS OFF SWITCH
HOMELINK UNIT
MICU
MOONROOF CONTROL UNIT/ MOTOR
OPTION CONNECTOR (FOR HEATED STEERING WHEEL)
OPTIONAL
PASSENGER'S UNDER-DASH FUSE/RELAY BOX STEERING WHEEL HEATER RELAY
PASSENGER'S VANITY MIRROR LIGHT
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
POWER TILT/ TELESCOPIC STEERING CONTROL UNIT
ROOF CONSOLE MODULE
SRS UNIT
STEERING COLUMN)
STEERING HEATER
STEREO AMPLIFIER
W/ NAVIGATION
W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM
W/O NAVIGATION
Go to component -> Ground distribution circuit, except hybrid (4 of 6) -> ELECTRICAL COMPASS UNIT
Wiring diagram electrical compass unit (3 of 3)
ANC/ACTIVE SOUND CONTROL UNIT
AUXILIARY UNDER-HOOD RELAY BLOCK
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX
DIODE A
ELECTRIC PARKING BRAKE CONTROL UNIT
ELECTRICAL COMPASS UNIT
EVAP CANISTER PURGE VALVE
FROM UNDER-DASH SUB RELAY BOX (DIAGRAM 7 OF 10)
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 24
FUSE 3
FUSE 4
FUSE 6
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEAD-UP WARNING UNIT
LEFT SIDE BSI RADAR UNIT
LT BLU WIRE
LT GRN WIRE
MAF/ IAT SENSOR
MICU
MILLIMETER WAVE RADAR UNIT
MULTIPURPOSE CAMERA UNIT
OPTIONAL CONNECTOR
PARKING, BACKUP SENSOR CONTROL UNIT
PARKING, BACKUP SENSOR SWITCH
PARKING, BACKUP SENSOR/ HEADLIGHT WASHER SWITCH
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PCM
POWER MIRROR CONTROL UNIT
POWER SEAT CONTROL UNIT
POWER TAILGATE CONTROL UNIT
POWER TILT/ TELESCOPIC STEERING CONTROL UNIT
RDM/LDW/VSA OFF SWITCH
REAR FUSE/RELAY BOX
REAR MICU
REAR WINDOW WASHER MOTOR RELAY
REAR WINDOW WIPER RELAY
RELAY CONTROL MODULE
REVERSE RELAY
RIGHT SIDE BSI RADAR UNIT
SBW SHIFTER CONTROL MODULE
STARTER CUT RELAY 1
STARTER CUT RELAY 2
TAN WIRE
TELEMATICS CONTROL UNIT/HANDSFREE LINK CONTROL UNIT
TRANSMISSION CONTROL MODULE
UNDER-HOOD FUSE/RELAY BOX
W/ HEADLIGHT WASHER
W/ HEADLIGHT WASHER W/O HEADLIGHT WASHER
W/O HEADLIGHT WASHER
WINDSHIELD WASHER MOTOR RELAY
WIPER MOTOR RELAY
Go to component -> Power distribution circuit, except hybrid (5 of 10) -> ELECTRICAL COMPASS UNIT
