Acura MDX III facelift 2 (2016-2021) battery current sensor Wiring diagram
This page shows the only wiring diagram for the component.battery current sensor, which is found in the car Acura MDX III facelift 2 (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram battery current sensor (1 of 1)
28-PIN CONNECTOR
BATTERY CONDITION MONITOR MODULE (ON HIGH VOLTAGE BATTERY)
BATTERY CURRENT SENSOR
BATTERY MODULE 2 (ON HIGH VOLTAGE BATTERY)
BLU WIRE
BRN WIRE
BYPASS CONTACTOR RELAY
BYPASS RESISTOR
GRN WIRE
GRY WIRE
HIGH VOLTAGE CONTACTOR RELAY
HIGH VOLTAGE SUB CONTACTOR RELAY
LT BLU WIRE
LT GRN WIRE
MAIN FUSE
NCA WIRE
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
TAN WIRE
TERMINAL BASE (SUB JUNCTION BOARD SIDE)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.0l hybrid, hybrid system circuit (3 of 8) -> BATTERY CURRENT SENSOR
