Acura MDX III facelift 2 (2016-2021) auxiliary under-hood relay block Wiring diagrams
This page contains all the electrical diagrams for the component. auxiliary under-hood relay block, in which he is found in the car Acura MDX III facelift 2 (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
auxiliary under-hood relay block wiring diagram (1 of 3)
ACTIVE CONTROL ENGINE MOUNT (ACM) CONTROL RELAY
AUXILIARY UNDER-DASH RELAY BLOCK A
AUXILIARY UNDER-DASH RELAY BLOCK B
AUXILIARY UNDER-DASH RELAY BLOCK C
AUXILIARY UNDER-HOOD RELAY BLOCK
BLU WIRE
BRN WIRE
DRIVER'S UNDER-DASH FUSE/RELAY BOX
FROM FUSE 1 (DIAGRAM 1 OF 10)
FRONT BLOWER MOTOR RELAY
FRONT PASSENGER'S POWER LUMBAR SUPPORT SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT SEAT HEATER RELAY
FUSE 11
FUSE 18
FUSE 2
FUSE 20
FUSE 22
FUSE 24
FUSE 25
FUSE 3
FUSE 3-1
FUSE 3-3
FUSE 3-4
FUSE 3-5
FUSE 3-6
FUSE 3-8
FUSE 31
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
GRY WIRE
HEADLIGHT RELAY
HEADLIGHT WASHER RELAY
HEATED WINDSHIELD WIPER AREA RELAY
LT BLU WIRE
MAIN UNDER- HOOD FUSE BOX
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PNK WIRE
POWER SEAT CONTROL UNIT/ ADJUSTMENT SWITCH
PPL
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY CONTROL MODULE
RIGHT REAR POWER WINDOW SWITCH
SBW SHIFTER CONTROL MODULE
SMALL LIGHT RELAY
STARTER CUT RELAY 1
STEERING WHEEL HEATER RELAY
STEREO AMPLIFIER
TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 1 OF 10)
TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 6 OF 10)
TO FUSE 3-2 (DIAGRAM 7 OF 10)
TO REAR FUSE/RELAY BOX (DIAGRAM 8 OF 10)
TO UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 8 OF 10)
TRANSMISSION CONTROL MODULE
UNDER-HOOD FUSE/RELAY BOX
W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM
W/O NAVIGATION W/ NAVIGATION
WHT WIRE
WIPER MOTOR RELAY
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (2 of 10) -> AUXILIARY UNDER-HOOD RELAY BLOCK
auxiliary under-hood relay block wiring diagram (2 of 3)
ANC/ACTIVE SOUND CONTROL UNIT
AUXILIARY UNDER-HOOD RELAY BLOCK
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX
DIODE A
ELECTRIC PARKING BRAKE CONTROL UNIT
ELECTRICAL COMPASS UNIT
EVAP CANISTER PURGE VALVE
FROM UNDER-DASH SUB RELAY BOX (DIAGRAM 7 OF 10)
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 24
FUSE 3
FUSE 4
FUSE 6
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEAD-UP WARNING UNIT
LEFT SIDE BSI RADAR UNIT
LT BLU WIRE
LT GRN WIRE
MAF/ IAT SENSOR
MICU
MILLIMETER WAVE RADAR UNIT
MULTIPURPOSE CAMERA UNIT
OPTIONAL CONNECTOR
PARKING, BACKUP SENSOR CONTROL UNIT
PARKING, BACKUP SENSOR SWITCH
PARKING, BACKUP SENSOR/ HEADLIGHT WASHER SWITCH
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PCM
POWER MIRROR CONTROL UNIT
POWER SEAT CONTROL UNIT
POWER TAILGATE CONTROL UNIT
POWER TILT/ TELESCOPIC STEERING CONTROL UNIT
RDM/LDW/VSA OFF SWITCH
REAR FUSE/RELAY BOX
REAR MICU
REAR WINDOW WASHER MOTOR RELAY
REAR WINDOW WIPER RELAY
RELAY CONTROL MODULE
REVERSE RELAY
RIGHT SIDE BSI RADAR UNIT
SBW SHIFTER CONTROL MODULE
STARTER CUT RELAY 1
STARTER CUT RELAY 2
TAN WIRE
TELEMATICS CONTROL UNIT/HANDSFREE LINK CONTROL UNIT
TRANSMISSION CONTROL MODULE
UNDER-HOOD FUSE/RELAY BOX
W/ HEADLIGHT WASHER
W/ HEADLIGHT WASHER W/O HEADLIGHT WASHER
W/O HEADLIGHT WASHER
WINDSHIELD WASHER MOTOR RELAY
WIPER MOTOR RELAY
Go to component -> Power distribution circuit, except hybrid (5 of 10) -> AUXILIARY UNDER-HOOD RELAY BLOCK
auxiliary under-hood relay block wiring diagram (3 of 3)
AUXILIARY UNDER-HOOD RELAY BLOCK
BATTERY
BATTERY SENSOR
BATTERY TERMINAL FUSE BOX
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S UNDER-DASH FUSE/RELAY BOX
ELECTRIC STEERING LOCK
ENGINE START/STOP SWITCH
FUSE 1
FUSE 12
FUSE 18
FUSE 3-5
FUSE 7
GRN WIRE
GRY WIRE
KEYLESS ACCESS/ TPMS CONTROL UNIT
LT BLU WIRE
MAGNETIC SWITCH
MAIN UNDER- HOOD FUSE BOX
PCM
PPL
RED WIRE
RELAY ENERGIZED
STARTER
STARTER CUT RELAY 1
STARTER CUT RELAY 2
STARTER MOTOR
TRANSMISSION CONTROL MODULE
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
Go to component -> Starting circuit, w/ auto idle stop -> AUXILIARY UNDER-HOOD RELAY BLOCK
