Acura MDX III facelift 2 (2016-2021) auxiliary under-dash relay block a Wiring diagrams
This page contains all the electrical diagrams for the component. auxiliary under-dash relay block a, in which he is found in the car Acura MDX III facelift 2 (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram auxiliary under-dash relay block a (1 of 5)
AUXILIARY UNDER-DASH RELAY BLOCK A
BLK WIRE
BLU WIRE
BRN WIRE
CANADA
COMPUTER DATA LINES SYSTEM
DRIVER'S UNDER-DASH FUSE/RELAY BOX
FUSE 11
FUSE 3-8 2-7
GRN WIRE
GRY WIRE
HEADLIGHT WASHER MOTOR
HEADLIGHT WASHER RELAY
HEADLIGHT WASHER SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
HYBRID EXCEPT HYBRID CANADA USA
LT GRN WIRE
MAIN UNDER- HOOD FUSE BOX
MICU
PARKING, BACKUP SENSOR/HEADLIGHT WASHER SWITCH
PNK WIRE
RED WIRE
RELAY CONTROL MODULE
USA
YEL WIRE
Go to component -> Headlamp washer circuit -> AUXILIARY UNDER-DASH RELAY BLOCK A
Wiring diagram auxiliary under-dash relay block a (2 of 5)
AUXILIARY UNDER-DASH FUSE BOX
AUXILIARY UNDER-DASH RELAY BLOCK A
BRN WIRE
CABLE REEL
FUSE 5
FUSE 8
GRN WIRE
HORN (HIGH)
HORN (LOW)
HORN RELAY
HORN SWITCH
HOT AT ALL TIMES
INSIDE STEERING WHEEL)
LT GRN WIRE
MAIN UNDER- HOOD FUSE BOX
PPL
RED WIRE
RELAY CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX
STEERING COLUMN)
W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM
Go to component -> Horn circuit, except hybrid -> AUXILIARY UNDER-DASH RELAY BLOCK A
Wiring diagram auxiliary under-dash relay block a (3 of 5)
A/C COMPRESSOR CLUTCH RELAY
A/C CONDENSER FAN RELAY
ALTERNATOR
AUXILIARY UNDER-DASH RELAY BLOCK A
AUXILIARY UNDER-DASH RELAY BLOCK B
BATTERY
BATTERY FAN MOTOR
BATTERY SENSOR
BATTERY TERMINAL FUSE BOX
BLK WIRE
BLU WIRE
BRAKE LIGHT RELAY
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CABLE REEL
DRIVER'S JUNCTION BOX B
DRIVER'S UNDER-DASH FUSE/RELAY BOX
EPS CONTROL UNIT
FROM MAIN UNDER-HOOD FUSE BOX (DIAGRAM 2 OF 10)
FROM MAIN UNDER-HOOD FUSE BOX (DIAGRAM 9 OF 10)
FRONT FOG LIGHT RELAY
FUSE 1
FUSE 10
FUSE 17
FUSE 18
FUSE 2-1
FUSE 2-2
FUSE 2-3
FUSE 2-4
FUSE 2-5
FUSE 2-6
FUSE 2-7
FUSE 2-8
FUSE 29
FUSE 30
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
HORN RELAY
LEFT HEADLIGHT
LT BLU WIRE
MAIN UNDER- HOOD FUSE BOX
MICU
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
POWER TAILGATE CONTROL UNIT
POWER TILT/ TELESCOPE STEERING CONTROL UNIT
RADIATOR FAN RELAY
REAR BLOWER MOTOR RELAY
REAR FUSE/ RELAY BOX
RED WIRE
RIGHT HEADLIGHT
STARTER
STEERING COLUMN)
STEERING COMMANDER SWITCH ASSEMBLY
TAN WIRE
TO AUXILIARY UNDER-DASH FUSE BOX (DIAGRAM 9 OF 10)
TO FUSE 7 (DIAGRAM 2 OF 10)
TO PASSENGER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 4 OF 10)
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (1 of 10) -> AUXILIARY UNDER-DASH RELAY BLOCK A
Wiring diagram auxiliary under-dash relay block a (4 of 5)
ACTIVE CONTROL ENGINE MOUNT (ACM) CONTROL RELAY
AUXILIARY UNDER-DASH RELAY BLOCK A
AUXILIARY UNDER-DASH RELAY BLOCK B
AUXILIARY UNDER-DASH RELAY BLOCK C
AUXILIARY UNDER-HOOD RELAY BLOCK
BLU WIRE
BRN WIRE
DRIVER'S UNDER-DASH FUSE/RELAY BOX
FROM FUSE 1 (DIAGRAM 1 OF 10)
FRONT BLOWER MOTOR RELAY
FRONT PASSENGER'S POWER LUMBAR SUPPORT SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT SEAT HEATER RELAY
FUSE 11
FUSE 18
FUSE 2
FUSE 20
FUSE 22
FUSE 24
FUSE 25
FUSE 3
FUSE 3-1
FUSE 3-3
FUSE 3-4
FUSE 3-5
FUSE 3-6
FUSE 3-8
FUSE 31
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
GRY WIRE
HEADLIGHT RELAY
HEADLIGHT WASHER RELAY
HEATED WINDSHIELD WIPER AREA RELAY
LT BLU WIRE
MAIN UNDER- HOOD FUSE BOX
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PNK WIRE
POWER SEAT CONTROL UNIT/ ADJUSTMENT SWITCH
PPL
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY CONTROL MODULE
RIGHT REAR POWER WINDOW SWITCH
SBW SHIFTER CONTROL MODULE
SMALL LIGHT RELAY
STARTER CUT RELAY 1
STEERING WHEEL HEATER RELAY
STEREO AMPLIFIER
TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 1 OF 10)
TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 6 OF 10)
TO FUSE 3-2 (DIAGRAM 7 OF 10)
TO REAR FUSE/RELAY BOX (DIAGRAM 8 OF 10)
TO UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 8 OF 10)
TRANSMISSION CONTROL MODULE
UNDER-HOOD FUSE/RELAY BOX
W/O AUTO IDLE STOP SYSTEM W/ AUTO IDLE STOP SYSTEM
W/O NAVIGATION W/ NAVIGATION
WHT WIRE
WIPER MOTOR RELAY
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (2 of 10) -> AUXILIARY UNDER-DASH RELAY BLOCK A
Wiring diagram auxiliary under-dash relay block a (5 of 5)
ANC/ACTIVE SOUND CONTROL UNIT
AUDIO UNIT/ AUDIO NAVIGATION UNIT
AUTOMATIC LIGHTING/ RAIN SENSOR
AUXILIARY UNDER-DASH FUSE BOX
AUXILIARY UNDER-DASH FUSE/RELAY BOX
AUXILIARY UNDER-DASH RELAY BLOCK A
BLU WIRE
BRN WIRE
CABLE REEL
CAN GATEWAY
CARPLAY, ANDROID AUTO UNIT
CENTER DISPLAY UNIT
DC-DC CONVERTER (W/ AUTO IDLE STOP SYSTEM) (BEHIND LEFT SIDE OF DASH)
FROM DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 10)
FROM MAIN UNDER-HOOD FUSE BOX (DIAGRAM 1 OF 10)
FUSE 1
FUSE 11
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
GRN WIRE
HORN RELAY
LT BLU WIRE
LT GRN WIRE
MAIN UNDER- HOOD FUSE BOX
MICU DRIVER'S UNDER-DASH FUSE/RELAY BOX
MULTI VIEW CAMERA UNIT
PCM
RED WIRE
RELAY CONTROL MODULE
SMALL LIGHT RELAY
STEERING COLUMN)
STEERING COMMANDER SWITCH ASSEMBLY
TELEMATICS CONTROL UNIT/ HANDSFREE LINK CONTROL UNIT
TO AUXILIARY UNDER-DASH FUSE/RELAY BOX (DIAGRAM 10 OF 10)
TO MAIN UNDER-HOOD FUSE BOX (DIAGRAM 1 OF 10)
TO REAR CONTROLLER, SCREEN (DIAGRAM 8 OF 10)
TO VSA MODULATOR CONTROL UNIT (DIAGRAM 3 OF 10)
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (9 of 10) -> AUXILIARY UNDER-DASH RELAY BLOCK A
