Acura MDX III facelift 2 (2016-2021) automatic brake hold switch Wiring diagrams
This page contains all the electrical diagrams for the component. automatic brake hold switch, in which he is found in the car Acura MDX III facelift 2 (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram automatic brake hold switch (1 of 2)
32-BIT MICROCOMPUTER + FLASH ROM
AMP
APPLY
AUTOMATIC BRAKE HOLD IND
AUTOMATIC BRAKE HOLD SWITCH
AUTOMATIC BRAKE HOLD SYSTEM IND
AUXILIARY UNDER- DASH FUSE/ RELAY BOX
BLK WIRE
BLU WIRE
BRAKE IND
BRAKE SYSTEM IND
BRN WIRE
COMPULSORY TURNING- ON CIRCUIT
COMPUTER DATA LINES SYSTEM
CRUISE LIGHT DIMMING CIRCUIT
DRIVER'S UNDER-DASH FUSE/RELAY BOX
ELECTRIC PARKING BRAKE CONTROL UNIT
ELECTRIC PARKING BRAKE IND
ELECTRIC PARKING BRAKE SWITCH
ELECTRIC PARKING BRAKE SWITCH/AUTOMATIC BRAKE HOLD SWITCH
ELECTRIC PARKING BRAKE SYSTEM IND
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE 11
FUSE 13
FUSE 15
FUSE 16
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
HOT W/ DC-DC
KEYLESS ACCESS/ TPMS CONTROL UNIT
LEFT REAR ELECTRIC PARKING BRAKE ACTUATOR
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
REAR FUSE/ RELAY BOX
RED WIRE
RELAY ENERGIZED
RELEASE
RIGHT REAR ELECTRIC PARKING BRAKE ACTUATOR
SPEAKER CIRCUIT
TAN WIRE
W/ AUTO IDLE STOP SYSTEM W/O AUTO IDLE STOP SYSTEM
WARNING DRIVER CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Electric parking brake circuit, except hybrid -> AUTOMATIC BRAKE HOLD SWITCH
Wiring diagram automatic brake hold switch (2 of 2)
AUTOMATIC BRAKE HOLD SWITCH
AUXILIARY UNDER-DASH FUSE/RELAY BOX
BLK WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
CENTER JUNCTION BOX
COMPUTER DATA LINES SYSTEM
ELECTRIC PARKING BRAKE CONTROL UNIT
ELECTRIC PARKING BRAKE/ AUTOMATIC BRAKE HOLD SWITCH
FUSE 7
GRN WIRE
GRY WIRE
HEAD-UP WARNING UNIT (IF EQUIPPED)
HOT W/ DC-DC CONVERTER
IDLE STOP OFF SWITCH
RED WIRE
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit, except hybrid (2 of 3) -> AUTOMATIC BRAKE HOLD SWITCH
