Acura MDX III facelift 2 (2016-2021) audio remote switch/ hft-navigation voice control switch Wiring diagram
This page shows the only wiring diagram for the component.audio remote switch/ hft-navigation voice control switch, which is found in the car Acura MDX III facelift 2 (2016-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram audio remote switch/ hft-navigation voice control switch (1 of 1)
AUDIO REMOTE SWITCH/ HFT-NAVIGATION VOICE CONTROL SWITCH
AUTOMATIC LIGHTING/ RAIN SENSOR
BLU WIRE
CABLE REEL
LEFT SIDE BSI RADAR UNIT
PNK WIRE
POWER SEAT CONTROL UNIT
REAR FUSE/ RELAY BOX REAR MICU
RIGHT SIDE BSI RADAR UNIT
STEERING COLUMN)
TAN WIRE
VENTILATED SEAT CONTROL UNIT/ FRONT SEAT HEATER CONTROL UNIT
Go to component -> Computer data lines circuit, hybrid (6 of 6) -> AUDIO REMOTE SWITCH/ HFT-NAVIGATION VOICE CONTROL SWITCH
