Acura MDX III facelift 2 (2016-2021) acc relay Wiring diagrams

This page contains all the electrical diagrams for the component. acc relay, in which he is found in the car Acura MDX III facelift 2 (2016-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram acc relay (1 of 4)

Wiring diagram acc relay for Acura MDX III facelift 2 (2016-2021) (1 of 4)

Get access

3.5L 3.0L HYBRID 3.5L W/O AUTO IDLE STOP SYSTEM 3.5L W/ AUTO IDLE STOP SYSTEM ACC RELAY BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR POWER TAILGATE/ FUEL FILL DOOR OPENER SWITCH EXCEPT HYBRID FUSE 3-2 FUSE 3-5 FUSE 3-7 FUSE 4 FUSE 8 FUSE HOLDER A FUSE HOLDER B GRN WIRE GRY WIRE HOT AT ALL TIMES KEYLESS ACCESS/TPMS CONTROL UNIT (RIGHT SIDE OF DASH) LEFT REAR DOOR OUTER HANDLE LOCK SWITCH LT BLU WIRE LT GRN WIRE MAIN UNDER- HOOD FUSE BOX NCA WIRE PNK WIRE POWER TAILGATE CONTROL UNIT POWER TAILGATE OUTER HANDLE SWITCH POWER TAILGATE SWITCH PPL RED WIRE RIGHT REAR DOOR OUTER HANDLE TAILGATE LATCH SWITCH TAN WIRE TOUCH SENSOR TRUNK, TAILGATE, FUEL DOORS SYSTEM UNDER-DASH SUB-RELAY BOX WHT WIRE YEL WIRE

Go to component -> Anti-theft circuit (5 of 6) -> ACC RELAY

Wiring diagram acc relay (2 of 4)

Wiring diagram acc relay for Acura MDX III facelift 2 (2016-2021) (2 of 4)

Get access

ACC RELAY BLK WIRE BLU WIRE BRN WIRE ELECTRIC STEERING LOCK ENGINE START/STOP SWITCH FROM DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 6 OF 10) FROM FUSE 3-1 (DIAGRAM 2 OF 10) FUSE 3-2 FUSE 3-7 GRN WIRE GRY WIRE IMMOBILIZER I/F KEYLESS ACCESS/TPMS CONTROL UNIT LF ANTENNA LT BLU WIRE LT GRN WIRE MAIN UNDER- HOOD FUSE BOX PNK WIRE PPL RED WIRE TAN WIRE TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 10) TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 4 OF 10) TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 5 OF 10) UNDER-DASH SUB-RELAY BOX WHT WIRE YEL WIRE

Go to component -> Power distribution circuit, except hybrid (7 of 10) -> ACC RELAY

Wiring diagram acc relay (3 of 4)

Wiring diagram acc relay for Acura MDX III facelift 2 (2016-2021) (3 of 4)

Get access

ACC RELAY BLK WIRE BLU WIRE BRAKE LIGHT RELAY BRAKE PEDAL POSITION SWITCH BRN WIRE DRIVER'S UNDER-DASH FUSE/RELAY BOX ELECTRIC PARKING BRAKE CONTROL UNIT ELECTRIC SERVO BRAKE CONTROL UNIT ENGINE START/STOP SWITCH EPS CONTROL UNIT FROM FUSE HOLDER A (DIAGRAM 2 OF 8) FROM FUSE HOLDER B (DIAGRAM 2 OF 8) FUSE 13 FUSE 21 FUSE 22 FUSE 23 FUSE 24 FUSE 28 GRN WIRE GRY WIRE IMMOBILIZER I/F KEYLESS ACCESS/ TPMS CONTROL UNIT KEYLESS ACCESS/TPMS CONTROL UNIT LF ANTENNA LT BLU WIRE LT GRN WIRE MAF/IAT SENSOR MICU PCM PGM-FI MAIN RELAY 2 PNK WIRE PPL RED WIRE STARTER CUT RELAY 1 STARTER CUT RELAY 2 STEERING ANGLE SENSOR TAN WIRE TO DRIVER'S JUNCTION BOX A (DIAGRAM 4 OF 8) TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 7 OF 8) TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 8 OF 8) TO PASSENGER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 4 OF 8) UNDER-DASH SUB-RELAY BOX UNDER-HOOD FUSE/RELAY BOX USB CHARGER UNIT B USB CHARGER UNIT C USB CHARGER UNIT D VSA MODULATOR CONTROL UNIT W/ REAR ENTERTAINMENT SYSTEM W/O REAR ENTERTAINMENT SYSTEM WHT WIRE YEL WIRE

Go to component -> Power distribution circuit, hybrid (5 of 8) -> ACC RELAY
