Acura MDX III facelift 2 (2016-2021) 12 volt battery terminal fuse box Wiring diagram

12 VOLT BATTERY 12 VOLT BATTERY SENSOR 12 VOLT BATTERY TERMINAL FUSE BOX BLK WIRE BLU WIRE BRAKE LIGHT RELAY BRAKE PEDAL POSITION SWITCH BRN WIRE ELECTRIC OIL PUMP RELAY ELECTRIC SERVO BRAKE CONTROL UNIT EPS CONTROL UNIT FRONT BLOWER MOTOR RELAY FUSE 1 FUSE 10 FUSE 18 FUSE 2-1 FUSE 2-2 FUSE 2-3 FUSE 2-4 FUSE 2-5 FUSE 2-6 FUSE 2-7 FUSE 2-8 FUSE 3-1 FUSE 3-2 FUSE 3-3 FUSE 3-4 FUSE 3-5 FUSE 3-6 FUSE 3-7 FUSE 3-8 FUSE 4 FUSE 5 FUSE 6 FUSE 7 FUSE 8 FUSE 9 GRN WIRE GRY WIRE HEADLIGHT WASHER RELAY HIGH VOLTAGE MPI CONNECTOR HORN RELAY LT BLU WIRE PCU PNK WIRE POWER TAILGATE CONTROL UNIT REAR BLOWER MOTOR RELAY REAR FUSE/ RELAY BOX REAR WINDOW DEFOGGER RELAY UNDER-HOOD FUSE/RELAY BOX RED WIRE RELAY HOLDER A RELAY HOLDER C RELAY HOLDER E STARTER TO 12 VOLT BATTERY FAN MOTOR (DIAGRAM 4 OF 8) TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 2 OF 8) TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 8) TO FUSE HOLDER A (DIAGRAM 2 OF 8) TO FUSE HOLDER B (DIAGRAM 2 OF 8) TO PASSENGER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 8) TO PASSENGER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 4 OF 8) TO REAR FUSE/RELAY BOX (DIAGRAM 6 OF 8) TO UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 2 OF 8) TO UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 6 OF 8) UNDER-HOOD FUSE/RELAY BOX VSA MODULATOR CONTROL UNIT WHT WIRE YEL WIRE
