Power tailgate circuit for Acura MDX III (2013-2015)
Power tailgate circuit (1 of 2)
+ FLASH ROOM
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 1
FUSE 18
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START DRIVER'S UNDER-DASH FUSE 11 FUSE/RELAY BOX (LEFT END OF DASH)
LEFT POWER TAILGATE PINCH SENSOR (LEFT SIDE OF TAILGATE)
LT BLU WIRE
LT GRN WIRE
MULTI INFORMATION DISPLAY (TFT)
ORG/ WIRE
PNK WIRE
POWER TAILGATE CONTROL UNIT (BEHIND LEFT REAR SIDE TRIM PANEL)
POWER TAILGATE DRIVE UNIT (BOTTOM LEFT CORNER OF TAILGATE)
POWER TAILGATE MOTOR
POWER TAILGATE RELAY
POWER TAILGATE SENSOR
PPL
REAR MICU
RED WIRE
RIGHT POWER TAILGATE PINCH SENSOR (RIGHT SIDE OF TAILGATE)
WHT WIRE
YEL WIRE
Power tailgate circuit (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CLOSER MOTOR
DRIVER'S DOOR POWER TAILGATE/ FUEL FILL DOOR OPENER SWITCH
DRIVER'S POWER WINDOW MASTER SWITCH
DRIVER'S UNDER- DASH FUSE/ RELAY BOX (LEFT END OF DASH)
FULL LATCH SWITCH
GRN WIRE
GRY WIRE
HALF LATCH SWITCH
KEYLESS ACCESS CONTROL UNIT (RIGHT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
MICU
NCA WIRE
ORG/ WIRE
POWER SEAT CONTROL UNIT (UNDER DRIVER'S SEAT)
POWER TAILGATE CLOSER UNIT (CENTER OF TAILGATE)
POWER TAILGATE INSIDE SWITCH
RATCHET SWITCH
RED WIRE
RELEASE NEUTRAL SWITCH SWITCH
TAILGATE LATCH SWITCH
TRANSMISSION RANGE SWITCH (TOP REAR OF TRANSMISSION HOUSING)
YEL WIRE
