Fuel door release circuit for Acura MDX III (2013-2015)
Fuel door release circuit
28 30 4 14 3 PNK WIRE
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S POWER TAILGATE/ FUEL FILL DOOR OPENER SWITCH
DRIVER'S POWER WINDOW MASTER SWITCH
FUEL FILL DOOR LOCK ACTUATOR (BEHIND FRONT OF LEFT REAR SIDE TRIM PANEL)
FUEL FILL DOOR OPENER RELAY
FUEL FILL DOOR OPENER SWITCH
FUSE 19
HOT AT ALL TIMES DRIVER'S UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH)
HOT AT ALL TIMES FUSE 4
LT GRN WIRE
ORG/ WIRE
PNK WIRE
REAR FUSE/RELAY BOX (BEHIND REAR OF LEFT REAR SIDE TRIM PANEL)
REAR MICU
WHT WIRE
