Supplemental restraints circuit for Acura MDX III (2013-2015)
Supplemental restraints circuit (1 of 4)
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (BEHIND STEERING COLUMN COVER)
COMPUTER DATA LINES SYSTEM
DRIVER'S AIR BAG INFLATOR (INSIDE STEERING WHEEL)
DRIVER'S JUNCTION BOX B (UPPER LEFT CENTER OF DASH)
DRIVER'S KNEE AIR BAG INFLATOR (UNDER LEFT SIDE OF DASH)
FRONT PASSENGER'S AIR BAG CUT-OFF
FRONT PASSENGER'S AIR BAG INFLATOR (RIGHT SIDE OF DASH)
FUSE FUSE
FUSE FUSE FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INDICATOR
LEFT FRONT IMPACT SENSOR (BEHIND LEFT END OF FRONT BUMPER)
LT BLU WIRE
LT GRN WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX (RIGHT KICK PANEL)
PPL
RED WIRE
RIGHT FRONT IMPACT SENSOR (BEHIND RIGHT END OF FRONT BUMPER)
SRS UNIT (UNDER FRONT OF CENTER CONSOLE)
WHT WIRE
YEL WIRE
Supplemental restraints circuit (2 of 4)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S E-PRETENSIONER UNIT (IF EQUIPPED) (BASE OF DRIVER'S "B" PILLAR)
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH (IN FRONT PASSENGER'S
FRONT PASSENGER'S WEIGHT SENSOR UNIT
GRN WIRE
GRY WIRE
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
SEAT BELT BUCKLE ASSEMBLY)
WHT WIRE
YEL WIRE
Supplemental restraints circuit (3 of 4)
32 BIT MICROCOMPUTER+FLASHROM
BLK WIRE
BLU WIRE
BRN WIRE
COMPULSORY TURNING- ON CIRCUIT
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT BELT BUCKLE SWITCH (IN DRIVER'S SEAT BELT BUCKLE ASSEMBLY)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH)
F-CAN L
F-CAN TRANSCEIVER F-CAN H
FAIL SAFE CIRCUIT
FUSE
GAUGE CONTROL MODULE
GRN WIRE
HALL IC HALL IC
HOT IN ON OR START
INDICATOR
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
RIGHT END OF DASH)
SEAT BELT REMINDER INDICATOR
SIDE AIR BAG CUT-OFF INDICATOR MULTI- INFORMATION
SRS INDICATOR
WARNING DRIVER CIRCUIT
WHT WIRE
YEL WIRE
Supplemental restraints circuit (4 of 4)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S SEAT POSITION SENSOR (UNDER DRIVER'S SEAT)
GRN WIRE
GRY WIRE
LEFT SIDE IMPACT SENSOR (FIRST) (BASE OF LEFT "B" PILLAR)
LEFT SIDE IMPACT SENSOR (SECOND) (IN LEFT "C" PILLAR)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
REAR SAFING SENSOR (UNDER MIDDLE OF REAR SEATS)
RED WIRE
RIGHT SIDE CURTAIN AIR BAG INFLATOR (TOP OF RIGHT "C" PILLAR)
RIGHT SIDE IMPACT SENSOR (FIRST) (BASE OF RIGHT "B" PILLAR)
RIGHT SIDE IMPACT SENSOR (SECOND) (IN RIGHT "C" PILLAR)
SRS UNIT (UNDER FRONT OF CENTER CONSOLE)
WHT WIRE
YEL WIRE
