Hands free module circuit, with navigation for Acura MDX III (2013-2015)

Hands free module circuit, with navigation (1 of 2)

MDX Acura III (2013-2015): Hands free module circuit, with navigation (1 of 2)

Get access

12 26 PPL ASSIST SW AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX (UPPER RIGHT CENTER OF DASH) COMPUTER DATA LINES SYSTEM DRIVER'S JUNCTION BOX A (BEHIND RIGHT SIDE OF INSTRUMENT CLUSTER) ENERGIZED MICU FUSE FUSE 13 FUSE 16 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ HOT W/ ACC RELAY ENERGIZED DRIVER'S UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) LINK SW LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE PPL RED WIRE ROOF CONSOLE MODULE SOUND SYSTEMS UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPT) WHT WIRE XM ANTENNA YEL WIRE

Hands free module circuit, with navigation (2 of 2)

MDX Acura III (2013-2015): Hands free module circuit, with navigation (2 of 2)

Get access

BLK WIRE BLU WIRE BRN WIRE DRIVER'S JUNCTION BOX B (UPPER LEFT CENTER OF DASH) GPS GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE PNK WIRE REAR SIDE TRIM PANEL) RED WIRE SRS UNIT (UNDER FRONT OF CENTER CONSOLE) WHT WIRE XM RECEIVER (BEHIND RIGHT YEL WIRE
