Courtesy lamps circuit for Acura MDX III (2013-2015)
Courtesy lamps circuit (1 of 3)
7 8 9 PPL
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SWITCH (IN DRIVER'S "B" PILLAR)
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVER'S VANITY MIRROR LIGHT
FRONT PASSENGER'S DOOR SWITCH (IN PASSENGER'S "B" PILLAR)
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHT CUT RELAY
LEFT REAR INDIVIDUAL MAP LIGHT (LED)
LT BLU WIRE
MAP LIGHT SWITCH
MICU
OPTION CONNECTOR (FOR LEFT LED)
OPTION CONNECTOR (FOR RIGHT LED)
ORG/ WIRE
PASSENGER'S VANITY MIRROR LIGHT
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
RIGHT REAR INDIVIDUAL MAP LIGHT (LED)
WHT WIRE
YEL WIRE
Courtesy lamps circuit (2 of 3)
7 8 9 PPL
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR
FUSE
GRN WIRE
GRY WIRE
ILLUM
INSTRUMENT ILLUMINATION CIRCUIT
LEFT CARGO AREA LIGHT
LEFT FRONT INDIVIDUAL MAP LIGHT
LEFT REAR DOOR SWITCH
LT BLU WIRE
MAP LIGHT SWITCH
ON OFF
ORG/ WIRE
PNK WIRE
POWER TAILGATE SWITCH
PPL
REAR FUSE/ RELAY BOX (BEHIND REAR OF LEFT REAR SIDE TRIM PANEL)
REAR MICU
RED WIRE
RELAY ENERGIZED
RIGHT CARGO AREA LIGHT
RIGHT FRONT INDIVIDUAL MAP LIGHT
RIGHT REAR DOOR SWITCH
ROOF CONSOLE MODULE
WHT WIRE
WHT/PNK WIRE
YEL WIRE
Courtesy lamps circuit (3 of 3)
BLU WIRE
DRIVER'S FOOTWELL LIGHT
FRONT PASSENGER'S FOOTWELL LIGHT
GRN WIRE
GRY WIRE
LEFT MIDDLE SEAT LOWER SWITCH
LEFT MIDDLE SEAT UPPER SWITCH
LEFT REAR DOOR COURTESY LIGHT
LT BLU WIRE
RED WIRE
RIGHT MIDDLE SEAT LOWER SWITCH
RIGHT MIDDLE SEAT UPPER SWITCH
RIGHT REAR DOOR COURTESY LIGHT
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
