Acura MDX III (2013-2015) ppl computer data lines system electronic power steering system Wiring diagram
This page shows the only wiring diagram for the component.ppl computer data lines system electronic power steering system, which is found in the car Acura MDX III (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl computer data lines system electronic power steering system (1 of 1)
10 11 12 13 14 15 16 PNK WIRE
4 12 PNK WIRE
AIR CONDITIONING SYSTEM
APP SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY)
AUDIO UNIT/ AUDIO NAVIGATION UNIT (W/ NAVIGATION)
BLK WIRE
BLU WIRE
BRN WIRE
COMPT)
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
DIODE C
ECT SENSOR 2 (LOWER LEFT REAR OF RADIATOR)
ELECTRONIC THROTTLE CONTROL SYSTEM (ETCS) CONTROL RELAY
FTP SENSOR (ON EVAP CANISTER ASSEMBLY)
FUSE
FUSE 10
FUSE 5
FUSE 9
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INJECTOR RELAY
LT BLU WIRE
LT GRN WIRE
MAF/IAT SENSOR (IN AIR INTAKE DUCT)
ORG/ WIRE
PCM (RIGHT FRONT OF ENGINE COMPT)
PGM-FI MAIN RELAY 1
PNK 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 WIRE
PNK PPL WIRE
PNK WIRE
PPL
PPL COMPUTER DATA LINES SYSTEM ELECTRONIC POWER STEERING SYSTEM
PPL PNK SHIFT INTERLOCK SYSTEM STARTING/ CHARGING SYSTEM WIRE
PPL PNK WIRE
PPL STARTING/ CHARGING SYSTEM
RADIATOR FAN RELAY
RED WIRE
TAN WIRE
UNDER- HOOD FUSE/ RELAY BOX (RIGHT REAR OF ENGINE
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.7l (1 of 9) -> PPL COMPUTER DATA LINES SYSTEM ELECTRONIC POWER STEERING SYSTEM
