Acura MDX III (2013-2015) pnk 22 19 16 12 Wiring diagram
This page shows the only wiring diagram for the component.pnk 22 19 16 12, which is found in the car Acura MDX III (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk 22 19 16 12 (1 of 1)
18 19 PNK WIRE
7 2 8 3 9 PNK WIRE
BLK WIRE
BLU WIRE
DRIVER'S JUNCTION BOX A (BEHIND RIGHT SIDE OF INSTRUMENT CLUSTER)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH)
LEFT SIDE BSI RADAR UNIT (IF EQUIPPED) (BEHIND LEFT END
LT BLU WIRE
MICU
OF REAR BUMPER)
OF REAR BUMPER) 17 18 19 20 21 22 23 24 25 PNK WIRE
OPTIONAL CONNECTOR
ORG/ WIRE
PARKING/ BACK-UP SENSOR CONTROL UNIT
PNK 1 2 3 4 5 6 WIRE
PNK 1 2 3 WIRE
PNK 14 13 WIRE
PNK 2 8 1 WIRE
PNK 22 19 16 12 WIRE
PNK 3 5 WIRE
PNK 3 9 WIRE
PNK PNK 5 4 WIRE
PNK WIRE
POWER SEAT CONTROL UNIT (IF EQUIPPED) (UNDER DRIVER'S SEAT)
POWER TAILGATE CONTROL UNIT (BEHIND LEFT REAR SIDE TRIM PANEL)
PPL
REAR FUSE/ RELAY BOX (BEHIND
REAR MICU
REAR OF LEFT REAR SIDE TRIM PANEL)
RED WIRE
RIGHT SIDE BSI RADAR UNIT (IF EQUIPPED) (BEHIND RIGHT END
WHT WIRE
Go to component -> Computer data lines circuit (2 of 4) -> PNK 22 19 16 12 WIRE
