Acura MDX III (2013-2015) park pin switch Wiring diagram
This page shows the only wiring diagram for the component.park pin switch, which is found in the car Acura MDX III (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park pin switch (1 of 1)
APP SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY)
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH (TOP OF BRAKE PEDAL ASSEMBLY)
CENTER JUNCTION BOX (UPPER RIGHT CENTER OF DASH)
COMPUTER DATA LINES SYSTEM
DRIVER'S UNDER-DASH FUSE/RELAY BOX
EXTERIOR PPL LIGHTS SYSTEM
FUSE
FUSE 11
FUSE 18 (LEFT END OF DASH)
GRN WIRE
HOT AT ALL TIMES
HOT ON ON OR START
KEYLESS ACCESS CONTROL UNIT
LT BLU WIRE
LT GRN WIRE
MAIN UNDER-HOOD FUSE/RELAY BOX (CENTER REAR OF ENGINE COMPT)
MICU
PARK PIN SWITCH
PARK PIN SWITCH/ SHIFT LOCK SOLENOID
PCM (RIGHT FRONT OF ENGINE COMPT)
PNK WIRE
PPL
PPL PPL
RED WIRE
SHIFT LOCK SOLENOID
TRANSMISSION RANGE SWITCH (TOP REAR OF TRANSMISSION HOUSING)
WHT WIRE
Go to component -> Shift interlock circuit -> PARK PIN SWITCH
