Acura MDX III (2013-2015) motor drive ic Wiring diagram
This page shows the only wiring diagram for the component.motor drive ic, which is found in the car Acura MDX III (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram motor drive ic (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 PNK WIRE
BLK WIRE
BLU WIRE
BOX (UPPER RIGHT CENTER OF DASH)
BRN WIRE
CENTER JUNCTION
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT CUSHION BLOWER MOTOR
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT- BACK HEATER
DRIVER'S SEAT-BACK BLOWER MOTOR
DRIVER'S UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH)
FRONT PASSENGER'S SEAT BACK HEATER
FRONT PASSENGER'S SEAT CUSHION BLOWER MOTOR
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT PASSENGER'S SEAT-BACK BLOWER MOTOR
FRONT SEAT HEATER RELAY
FUSE
FUSE 26
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
MOTOR DRIVE IC
ORG/ WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX (RIGHT KICK PANEL)
PNK WIRE
PPL
RED WIRE
WHT WIRE
Go to component -> Front heated seats circuit -> MOTOR DRIVE IC
