Acura MDX III (2013-2015) left rear left power middle window seat upper switch switch Wiring diagram
This page shows the only wiring diagram for the component.left rear left power middle window seat upper switch switch, which is found in the car Acura MDX III (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear left power middle window seat upper switch switch (1 of 1)
BASE
BLK WIRE
BRN WIRE
CABLE REEL (BEHIND STEERING COLUMN COVER)
CANADA
CONSOLE ACCESSORY POWER SOCKET RELAY
CRUISE CONTROL COMBINATION SWITCH
DASHLIGHTS (W/O ACC, BRIGHTNESS CMBS) CONTROL VSA OFF SWITCH SWITCH
EXCEPT BASE
FRONT ACCESSORY POWER SOCKET RELAY
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT SEAT HEATER RELAY
FUEL FILL DOOR LOCK ACTUATOR
FUEL PUMP CONTROL MODULE
GAUGE CONTROL MODULE
GLOVE CONSOLE BOX BOX LIGHT LIGHT
INTEGRATED DYNAMICS SYSTEM SWITCH
LEFT BRAKE LIGHT
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
LEFT REAR LEFT POWER MIDDLE WINDOW SEAT UPPER SWITCH SWITCH
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILLIGHT
PADDLE SHIFTER + (UPSHIFT SWITCH)
PADDLE SHIFTER - (DOWNSHIFT SWITCH)
PARKING, BACKUP SENSOR CONTROL UNIT
PASSENGER'S VANITY MIRROR LIGHT
REAR ACCESSORY POWER SOCKET RELAY
REAR CONTROLLER, SCREEN
REAR MICU
RIGHT POWER MIRROR
STEERING ANGLE SENSOR
USA
Go to component -> Ground distribution circuit (5 of 6) -> LEFT REAR LEFT POWER MIDDLE WINDOW SEAT UPPER SWITCH SWITCH
