Acura MDX III (2013-2015) left middle seat lower switch Wiring diagrams
This page contains all the electrical diagrams for the component. left middle seat lower switch, in which he is found in the car Acura MDX III (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left middle seat lower switch (1 of 2)
BLU WIRE
DRIVER'S FOOTWELL LIGHT
FRONT PASSENGER'S FOOTWELL LIGHT
GRN WIRE
GRY WIRE
LEFT MIDDLE SEAT LOWER SWITCH
LEFT MIDDLE SEAT UPPER SWITCH
LEFT REAR DOOR COURTESY LIGHT
LT BLU WIRE
RED WIRE
RIGHT MIDDLE SEAT LOWER SWITCH
RIGHT MIDDLE SEAT UPPER SWITCH
RIGHT REAR DOOR COURTESY LIGHT
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
Go to component -> Courtesy lamps circuit (3 of 3) -> LEFT MIDDLE SEAT LOWER SWITCH
Wiring diagram left middle seat lower switch (2 of 2)
BLK WIRE
BLU WIRE
FUSE 13
FUSE 5
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT MIDDLE SEAT LOWER SWITCH
LEFT MIDDLE SEAT UPPER SWITCH
LEFT SECOND ROW SEAT ACTUATOR
LT GRN WIRE
REAR FUSE/ RELAY BOX (BEHIND REAR OF LEFT REAR SIDE TRIM PANEL)
REAR MICU
RED WIRE
RIGHT MIDDLE SEAT LOWER SWITCH
RIGHT MIDDLE SEAT UPPER SWITCH
RIGHT SECOND ROW SEAT ACTUATOR
SLIDE ACTUATOR RELAY
YEL WIRE
Go to component -> Second row seats circuit -> LEFT MIDDLE SEAT LOWER SWITCH
