Acura MDX III (2013-2015) left electronic magnetic coil Wiring diagram
This page shows the only wiring diagram for the component.left electronic magnetic coil, which is found in the car Acura MDX III (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left electronic magnetic coil (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CIRCUIT WARNING DRIVER
COMPUTER DATA LINES SYSTEM
DRIVER'S UNDER-DASH FUSE/RELAY
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE (CENTER REAR OF ENGINE COMPT)
FUSE BOX (LEFT END OF DASH)
FUSE BOX (RIGHT KICK PANEL)
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
LEFT ELECTRONIC MAGNETIC COIL
LEFT SEARCH COIL
LT BLU WIRE
MAIN UNDER-HOOD FUSE/RELAY BOX
ORG/ WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY
PNK WIRE
RED WIRE
RIGHT ELECTRONIC MAGNETIC COIL
SH-AWD CONTROL UNIT (BEHIND LEFT REAR SIDE TRIM PANEL)
SH-AWD IND
WHT WIRE
YEL WIRE
Go to component -> Awd circuit -> LEFT ELECTRONIC MAGNETIC COIL
