Acura MDX III (2013-2015) hot at all times passenger's under-dash Wiring diagram
This page shows the only wiring diagram for the component.hot at all times passenger's under-dash, which is found in the car Acura MDX III (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot at all times passenger's under-dash (1 of 1)
10 11 12 13 14 15 16 PNK WIRE
ACTIVE CONTROL ENGINE MOUNT (ACM) CONTROL RELAY
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
FUEL PUMP CONTROL MODULE (BEHIND LEFT REAR SIDE TRIM PANEL)
FUEL TANK UNIT (TOP OF FUEL TANK)
FUSE 20
FUSE 3
FUSE/RELAY BOX (RIGHT KICK PANEL)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES PASSENGER'S UNDER-DASH
INJECTOR CONTROL MODULE (TOP FRONT OF ENGINE)
INSTRUMENT CLUSTER SYSTEM
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 WIRE
PNK WIRE
PPL
PPL PNK WIRE
RED WIRE
TAN WIRE
W/ ACC
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.7l (2 of 9) -> HOT AT ALL TIMES PASSENGER'S UNDER-DASH
