Acura MDX III (2013-2015) hot at all times fuse 4 Wiring diagram
This page shows the only wiring diagram for the component.hot at all times fuse 4, which is found in the car Acura MDX III (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot at all times fuse 4 (1 of 1)
28 30 4 14 3 PNK WIRE
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S POWER TAILGATE/ FUEL FILL DOOR OPENER SWITCH
DRIVER'S POWER WINDOW MASTER SWITCH
FUEL FILL DOOR LOCK ACTUATOR (BEHIND FRONT OF LEFT REAR SIDE TRIM PANEL)
FUEL FILL DOOR OPENER RELAY
FUEL FILL DOOR OPENER SWITCH
FUSE 19
HOT AT ALL TIMES DRIVER'S UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH)
HOT AT ALL TIMES FUSE 4
LT GRN WIRE
ORG/ WIRE
PNK WIRE
REAR FUSE/RELAY BOX (BEHIND REAR OF LEFT REAR SIDE TRIM PANEL)
REAR MICU
WHT WIRE
Go to component -> Fuel door release circuit -> HOT AT ALL TIMES FUSE 4
