Acura MDX III (2013-2015) front passenger's seat slide motor Wiring diagram
This page shows the only wiring diagram for the component.front passenger's seat slide motor, which is found in the car Acura MDX III (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's seat slide motor (1 of 1)
BACKWARD
BLK WIRE
BLU WIRE
DOWN
FORWARD/
FRONT PASSENGER'S SEAT FRONT UP-DOWN MOTOR
FRONT PASSENGER'S SEAT REAR UP-DOWN MOTOR
FRONT PASSENGER'S SEAT RECLINE MOTOR
FRONT PASSENGER'S SEAT SLIDE MOTOR
FUSE 7
FUSE 8
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
ORG/ WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX (RIGHT KICK PANEL)
PNK WIRE
POWER SEAT CONTROL UNIT (UNDER DRIVER'S SEAT)
PPL
WHT WIRE
YEL WIRE
Go to component -> Front passenger power seat circuit -> FRONT PASSENGER'S SEAT SLIDE MOTOR
