Acura MDX III (2013-2015) front passenger's door inner handle light Wiring diagram
This page shows the only wiring diagram for the component.front passenger's door inner handle light, which is found in the car Acura MDX III (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's door inner handle light (1 of 1)
CENTER JUNCTION BOX (UPPER RIGHT CENTER OF DASH)
CMBS/ VSA OFF SWITCH
DRIVER'S DOOR INNER HANDLE LIGHT
FRONT PASSENGER'S AIR BAG CUTOFF INDICATOR
FRONT PASSENGER'S DOOR INNER HANDLE LIGHT
GRY WIRE
PARKING, BACKUP SENSOR SWITCH
REAR INDIVIDUAL MAP LIGHT
RED WIRE
ROOF CONSOLE MODULE
VSA OFF SWITCH
W/ ACC, CMBS
W/O ACC, CMBS
Go to component -> Instrument illumination circuit (2 of 4) -> FRONT PASSENGER'S DOOR INNER HANDLE LIGHT
