Acura MDX III (2013-2015) driver's power power mirror window switch master switch Wiring diagram
This page shows the only wiring diagram for the component.driver's power power mirror window switch master switch, which is found in the car Acura MDX III (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's power power mirror window switch master switch (1 of 1)
A/C COMPRESSOR CLUTCH RELAY
AUTOMATIC
BLU WIRE
BRAKE PEDAL POSITION SWITCH
CENTER JUNCTION BOX
CLIMATE CONTROL UNIT
CLIMATE FRONT CONTROL BLOWER SWITCH MOTOR RELAY
DIMMING INSIDE MIRROR
DIODE
DRIVER'S POWER POWER MIRROR WINDOW SWITCH MASTER SWITCH
ELECTRIC STEERING LOCK
EPS CONTROL UNIT
FROM UNDER-DASH SUB RELAY BOX (DIAGRAM 7 OF 8)
FRONT SEAT HEATER RELAY
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 26
FUSE 27
GRN WIRE
HEATER STEERING WHEEL RELAY
KEYLESS ACCESS CONTROL UNIT
LT GRN WIRE
OPTIONAL CONNECTOR
ORG/ WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX (RIGHT KICK PANEL)
PCM
PGM-FI MAIN RELAY 2
REAR BLOWER MOTOR RELAY
REAR CLIMATE CONTROL PANEL
REAR FUSE/ RELAY BOX (BEHIND REAR OF LEFT REAR SIDE TRIM PANEL)
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY CONTROL MODULE (IN UNDER-HOOD FUSE/RELAY BOX)
SECOND ROW SEAT HEATER RELAY (W/ NAVIGATION)
STARTER CUT REALY 1
STARTER CUT REALY 2
STEERING ANGLE SENSOR
TO AC INVERTER UNIT (DIAGRAM 4 OF 8)
TO PASSENGER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 6 OF 8)
UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPT)
VSA MODULATOR CONTROL UNIT
W/O NAVIGATION
YEL WIRE
Go to component -> Power distribution circuit (3 of 8) -> DRIVER'S POWER POWER MIRROR WINDOW SWITCH MASTER SWITCH
