Acura MDX III (2013-2015) driver's junction Wiring diagrams
This page contains all the electrical diagrams for the component. driver's junction, in which he is found in the car Acura MDX III (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver's junction (1 of 2)
AIR CONDITIONING SYSTEM
AUTOMATIC LIGHTING SENSOR (BASE) (TOP CENTER OF WINDSHIELD)
AUTOMATIC LIGHTING/ RAIN SENSOR (EXCEPT BASE) (TOP CENTER OF WINDSHIELD)
BLK WIRE
BLU WIRE
BOX (LEFT END OF DASH)
BOX A (BEHIND RIGHT SIDE OF INSTRUMENT CLUSTER)
BRN WIRE
CLIMATE CONTROL UNIT (LOWER RIGHT SIDE OF HVAC BLOWER HOUSING)
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
DIMMER/ FLASH-TO- PASS SWITCH
DRIVER'S JUNCTION
DRIVER'S JUNCTION BOX A (BEHIND RIGHT SIDE OF INSTRUMENT CLUSTER)
DRIVER'S UNDER-DASH FUSE/RELAY
EXCEPT BASE
FUSE 11
FUSE 30
GRN WIRE
GRY WIRE
HEAD
HEADLIGHT SWITCH
HOT AT ALL TIMES
HOT W/
LT BLU WIRE
LT GRN WIRE
MICU
OFF
OFF PARK AUTO HEAD
ORG/ WIRE
PARK AUTO
PASS
PNK WIRE
PPL
WHT WIRE
Go to component -> Headlamps circuit (1 of 3) -> DRIVER'S JUNCTION
Wiring diagram driver's junction (2 of 2)
ASSEMBLY
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLU WIRE
BOX A (BEHIND RIGHT SIDE OF INSTRUMENT CLUSTER)
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE LIGHT DIMMING CIRCUIT
DRIVER'S JUNCTION
FRONT FOG LIGHT RELAY
FRONT LIGHTS ON FOG LIGHT IND IND
FUSE
FUSE 18
FUSE 3-6
FUSE FUSE
GAUGE CONTROL MODULE
GRN WIRE
HEADLIGHT RELAY
HIGH BEAM IND
HOT AT ALL TIMES
MAIN UNDER-HOOD FUSE BOX (CENTER REAR OF ENGINE COMPT)
OPTION CONNECTOR (FOR FOG LIGHT) (BEHIND RIGHT END OF FRONT BUMPER)
PARKING BRAKE SWITCH (TOP OF PARKING BRAKE
PNK WIRE
PPL
UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPT)
WARNING DRIVER CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Headlamps circuit (2 of 3) -> DRIVER'S JUNCTION
