Rear camera circuit, except base for Acura MDX II facelift (2010-2013)
Rear camera circuit, except base
ATP-R
BACK LT-
BLK WIRE
BRN WIRE
CAMERA ADPT
CAMERA BIT 0
CAMERA BIT 1
CAMERA SHIELD
CAMERA VCC
CAMERA VIDEO
FUSE 21
FUSE 7
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
J/C
NAVIGATION DISPLAY UNIT
PCM (RIGHT FRONT OF ENGINE COMPT)
PPL
REARVIEW CAMERA (CENTER OF TAILGATE)
RED WIRE
TRANSMISSION HOUSING)
TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT MICU KICK PANEL)
WHT WIRE
YEL WIRE
