Acura MDX II facelift (2010-2013) vbu b-can fuel open Wiring diagram
This page shows the only wiring diagram for the component.vbu b-can fuel open, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vbu b-can fuel open (1 of 1)
+B BACKUP
B-CAN
BLK WIRE
BRN WIRE
DRIVER'S MPCS UNIT (IN DRIVER'S DOOR)
FUEL FILL DOOR OPENER SOLENOID (LEFT SIDE OF CARGO AREA)
FUEL LID
FUSE 7
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
MICU
PNK 1 WIRE
PNK WIRE
REAR FUSE/ RELAY BOX (LEFT SIDE OF CARGO AREA)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
VBU B-CAN FUEL OPEN
WHT WIRE
Go to component -> Fuel door release circuit -> VBU B-CAN FUEL OPEN
