Acura MDX II facelift (2010-2013) usa: advance, advance/ entertainment package Wiring diagram
This page shows the only wiring diagram for the component.usa: advance, advance/ entertainment package, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram usa: advance, advance/ entertainment package (1 of 1)
AMBIENT LIGHT
BLK WIRE
BSI OFF SWITCH
CANADA: ELITE PACKAGE
DRIVER'S AMBIENT LIGHT
DRIVER'S SEAT HEATER SWITCH
DRIVER'S SEAT VENTILATION SWITCH
FRONT PASSENGER'S AMBIENT LIGHT
FRONT PASSENGER'S SEAT HEATER SWITCH
FRONT PASSENGER'S SEAT VENTILATION SWITCH
HAZARD WARNING SWITCH/FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
HEADLIGHT WASHER SWITCH (CANADA)
LEFT MAP LIGHT SWITCH LIGHT
LT BLU WIRE
MOONROOF SWITCH
PACKAGE
PACKAGE, CANADA: BASE, TECH-E
POWER MIRROR SWITCH
REAR INDIVIDUAL
RED WIRE
RIGHT MAP LIGHT SWITCH LIGHT
ROOF CONSOLE
TECH-E
USA: ADVANCE, ADVANCE/ ENTERTAINMENT PACKAGE
USA: ADVANCE, ADVANCE/ ENTERTAINMENT; CANADA
USA: ADVANCE, ADVANCE/ ENTERTAINMENT; CANADA: ELITE
USA: BASE, TECH, TECH/ ENTERTAINMENT; CANADA: BASE,
USA: BASE, TECHNOLOGY, TECHNOLOGY/ ENTERTAINMENT;
VSA OFF SWITCH (BASE, TECH-E)
VSA/BSI OFF SWITCH
WHT WIRE
Go to component -> Instrument illumination circuit (2 of 3) -> USA: ADVANCE, ADVANCE/ ENTERTAINMENT PACKAGE
