Acura MDX II facelift (2010-2013) taillight headlight relay high beam relay Wiring diagram
This page shows the only wiring diagram for the component.taillight headlight relay high beam relay, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram taillight headlight relay high beam relay (1 of 1)
A/C COMPRESSOR CLUTCH RELAY
A/C CONDENSER FAN RELAY
AUXILIARY UNDER-DASH RELAY BLOCK C (BEHIND RIGHT KICK PANEL)
AUXILIARY UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BRAKE LIGHT RELAY AUXILIARY UNDER-DASH RELAY BLOCK C (BEHIND RIGHT KICK PANEL)
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CMP PCM CKP SENSOR SENSOR
CONTROL BLOCK
DRL SENSOR
ELD UNIT
ETCS CONTROL PGM-FI SUB RELAY RELAY
FOG LIGHT INTERIOR RELAY LIGHTS RELAY AUXILIARY UNDER-HOOD RELAY BLOCK
FROM FUSE 7 (DIAGRAM 1 OF 6)
FROM MULTI-FUSE 1 (DIAGRAM 1 OF 6)
FRONT BLOWER MOTOR RELAY
FUSE 1
FUSE 1 (TECH)
FUSE 10 FUSE 11
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 17
FUSE 2
FUSE 22 FUSE 12
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
HEADLIGHT LOW BEAM RELAY
HEADLIGHT WASHER RELAY (CANADA)
HORN RELAY
IGNITION COIL RELAY
INJECTOR
INJECTOR INJECTOR
INJECTOR INJECTOR INJECTOR
LEFT DRL
LT GRN WIRE
MAF/IAT SENSOR
MULTI FUSE 3
ORG/ WIRE
PCM
PGM-FI MAIN RELAY 1
PGM-FI MAIN RELAY 2 (FUEL PUMP)
PNK WIRE
PPL
R/B FUSE
RADIATOR FAN RELAY
RADIATOR FAN RELAY DIODE
RED WIRE
RIGHT DRL
SHORT PIN
TAILLIGHT HEADLIGHT RELAY HIGH BEAM RELAY
TECH FUSE
TECH RELAY
TO FUSE 23 (DIAGRAM 4 OF 6)
TO RR F/B MAIN (DIAGRAM 3 OF 6)
TRAILER ELECTRIC BRAKE CONNECTOR (ACCESSORY INSTALLED)
UNDER-DASH FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 6) -> TAILLIGHT HEADLIGHT RELAY HIGH BEAM RELAY
