Acura MDX II facelift (2010-2013) stereo audio amplifier unit Wiring diagram
This page shows the only wiring diagram for the component.stereo audio amplifier unit, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stereo audio amplifier unit (1 of 1)
AC INVERTER UNIT
AUDIO- NAVIGATION UNIT
BASE
BLK WIRE
BRN WIRE
DLC
EXCEPT BASE
GRN/WHT WIRE
HIGH MOUNT BRAKE LIGHT
HIGH MOUNT BRAKE LIGHT NOISE CONDENSER
KEYLESS BUZZER
LEFT BACKUP LIGHT
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT SECOND ROW SEAT HEATER SWITCH
MICU
PARK PIN SWITCH
POWER TAILGATE CLOSER MOTOR SHIELD
POWER TAILGATE CONTROL UNIT
POWER TAILGATE DRIVER UNIT POWER TAILGATE INSIDE BEEPER
POWER TAILGATE MOTOR SHIELD
POWER TILT/ TELESCOPIC STEERING CONTROL UNIT
REAR ACCESSORY POWER SOCKET
REAR BLOWER MOTOR RELAY
REAR BLOWER POWER TRANSISTOR
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER NOISE REDUCTION CONDENSER
RIGHT BACKUP LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT SECOND ROW SEAT HEATER SWITCH
SH-AWD CONTROL UNIT
SHIFT LOCK SOLENOID/PARK PIN SWITCH/ A/T GEAR POSITION INDICATOR PANEL LIGHT
STEREO AUDIO AMPLIFIER UNIT
USA: TECH, BASE, ADVANCE, CANADA: BASE
USA: TECH/ENTERTAINMENT, ADVANCE/ENTER- TAINMENT, CANADA: TECH-E, ELITE
Go to component -> Ground distribution circuit (5 of 5) -> STEREO AUDIO AMPLIFIER UNIT
