Acura MDX II facelift (2010-2013) right yoke solenoid Wiring diagram
This page shows the only wiring diagram for the component.right yoke solenoid, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right yoke solenoid (1 of 1)
A/T TEMPERATURE IND
AUXILIARY UNDER-DASH FUSE HOLDER 1 (BEHIND LEFT KICK PANEL) FUSE 2 SVTM-4
AUXILIARY UNDER-DASH RELAY BLOCK B (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUITS
F-CAN TRANSCEIVER
FSR TCH WRITE ENABLE CAN-L
FUSE
FUSE 7 RELAY BOX (BEHIND LEFT KICK PANEL)
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
K LINE
LEFT CLUTCH LEFT ELECTROMAGNETIC SEARCH COIL COIL
LEFT YOKE SOLENOID
LFH
LT BLU WIRE
LT GRN WIRE
MAIN UNDER-HOOD FUSE BOX MULTI FUSE 2
ORG/ WIRE
PPL
PWR PG LG 2 LCH LCL RCH RCL
REAR DIFFERENTIAL FLUID TEMPERATURE SENSOR
RED WIRE
RFH
RIGHT CLUTCH ELECTROMAGNETIC COIL
RIGHT SEARCH COIL
RIGHT YOKE SOLENOID
SH-AWD CONTROL UNIT (LEFT SIDE OF CARGO AREA)
SH-AWD FUSE
SH-AWD IND
SH-AWD RELAY
TOL LG 1 CAN-H LFL RFL
UNDER-DASH FUSE/
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
WHT WIRE
YEL WIRE
Go to component -> Awd circuit -> RIGHT YOKE SOLENOID
