Acura MDX II facelift (2010-2013) rear defogger Wiring diagram
This page shows the only wiring diagram for the component.rear defogger, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear defogger (1 of 1)
B-CAN
BLK WIRE
CLIMATE CONTROL UNIT
COMPUTER DATA LINES PNK SYSTEM WIRE
FUSE 10
FUSE 30
GRN WIRE
HOT AT ALL TIMES
HOT IN ON
LT GRN WIRE
MICU PNK WIRE
PNK WIRE
REAR DEFOGGER
REAR DEFOGGER NOISE CONDENSER
REAR FUSE/RELAY BOX (LEFT SIDE OF CARGO AREA)
REAR WINDOW DEFOGGER IND
REAR WINDOW DEFOGGER RELAY
REAR WINDOW DEFOGGER SWITCH
RED WIRE
RR DEF
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
Go to component -> Rear defogger circuit -> REAR DEFOGGER
