Acura MDX II facelift (2010-2013) power tilt/ steering telescopic angle steering sensor control unit wiring diagram
This page shows the only wiring diagram for the component.power tilt/ steering telescopic angle steering sensor control unit, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
power tilt/ steering telescopic angle steering sensor control unit wiring diagram (1 of 1)
ACTIVE HEADLIGHT DAMPER LEVELING CONTROL UNIT CONTROL UNIT ACC UNIT
BLK WIRE
BRAIDED WIRE
BRAKE ELD FLUID LEVEL UNIT SWITCH
BRN WIRE
BRN/YEL WIRE
CABLE REEL (BEHIND STEERING COLUMN COVER)
CLIMATE CONTROL UNIT
CONTROL BLOCK
CRUISE CONTROL COMBINATION SWITCH
DRIVER'S SEAT HEATER SWITCH
FRONT ACCESSORY POWER SOCKET
FRONT BLOWER FAN MOTOR CONTROL RELAY RELAY
FRONT BLOWER POWER TRANSISTOR
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
FRONT PASSENGER'S MPCS UNIT
FRONT PASSENGER'S SEAT HEATER SWITCH
FRONT WASHER RIGHT REAR MOTOR SIDE RELAY MARKER LIGHT
GLOVE BOX LIGHT
HANDS FREELINK CONTROL UNIT
LEFT BSI RADAR
LT GRN WIRE
MAIN UNDER-HOOD FUSE/RELAY BOX (LEFT FRONT OF ENGINE COMPT)
MILLIMETER WAVE RADAR UNIT SHIELD
NCA WIRE
PNK WIRE
POWER TILT/ STEERING TELESCOPIC ANGLE STEERING SENSOR CONTROL UNIT
PSP SWITCH
REAR CLIMATE CONTROL PANEL
REAR WASHER MOTOR RELAY
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT POWER MIRROR
RIGHT POWER MIRROR FRONT POSITION PASSENGER'S SENSOR MPCS UNIT
RIGHT POWER MIRROR RIGHT SIDE RIGHT TURN POWER MIRROR DEFOGGER SIGNAL LIGHT
RIGHT REAR TURN SIGNAL LIGHT
STEERING WHEEL)
TPMS CONTROL UNIT
USA: ADVANCE, ADVANCE/ENTERTAINMENT; CANADA: ELITE
YAW RATE, LATERAL, LONGITUDINAL ACCELERATION SENSOR
Go to component -> Ground distribution circuit (2 of 5) -> POWER TILT/ STEERING TELESCOPIC ANGLE STEERING SENSOR CONTROL UNIT
