Acura MDX II facelift (2010-2013) passenger's seat back) Wiring diagram
This page shows the only wiring diagram for the component.passenger's seat back), which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's seat back) (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
DRIVER'S SEAT BACK FAN MOTOR (LEFT SIDE OF DRIVER'S SEAT BACK)
DRIVER'S SEAT CUSHION FAN MOTOR (UNDER DRIVER'S SEAT)
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT HEATER
DRIVER'S SEAT- BACK HEATER
FAN INDICATOR
FAN SWITCH
FRONT PASSENGER'S SEAT BACK FAN MOTOR (LEFT SIDE OF FRONT
FRONT PASSENGER'S SEAT CUSHION FAN MOTOR (UNDER FRONT
FRONT PASSENGER'S SEAT VENTILATION SWITCH
FRONT SEAT HEATER RELAY
FUSE 30
FUSE 4
GRN WIRE
HEATER INDICATOR
HEATER SWITCH
HOT AT ALL TIMES
HOT IN ON
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASSENGER'S SEAT BACK)
PASSENGER'S SEAT)
PNK 2 1 WIRE
PNK 2 3 4 5 6 7 8 9 WIRE
PNK 2 3 WIRE
PNK WIRE
PPL
RED WIRE
SWITCH LIGHT
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
WHT WIRE
YEL WIRE
Go to component -> Seat ventilation circuit (2 of 2) -> PASSENGER'S SEAT BACK)
