Acura MDX II facelift (2010-2013) millimeter wave radar unit (front of Wiring diagram
This page shows the only wiring diagram for the component.millimeter wave radar unit (front of, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram millimeter wave radar unit (front of (1 of 1)
ACC UNIT (BEHIND RIGHT KICK PANEL)
ACTIVE DAMPER SYSTEM IND
ACTIVE DAMPER SYSTEM SWITCH
ARC SG
ARC SVCC
AUXILIARY UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BRN WIRE
BSI UNIT (LEFT SIDE OF CARGO AREA)
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUITS
DRIVER'S SEAT VENTILATION SWITCH
E-PRETENSIONER UNIT (UNDER CENTER CONSOLE)
ENGINE COMPT)
FRONT PASSENGER'S SEAT VENTILATION SWITCH
FUSE 21
FUSE 7
GAUGE CONTROL MODULE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT BSI RADAR
LEFT REAR VERTICAL ACCELERATION SENSOR (LEFT SIDE OF CARGO AREA)
LT BLU WIRE
LT GRN WIRE
MILLIMETER WAVE RADAR UNIT (FRONT OF
NCA WIRE
ORG/ WIRE
PNK WIRE
PPL
REAR FUSE/ RELAY BOX (LEFT SIDE OF CARGO AREA) MICU
RED WIRE
RIGHT BSI RADAR
RIGHT FRONT SUSPENSION STROKE SENSOR (ON RIGHT FRONT SUSPENSION)
RIGHT REAR VERTICAL ACCELERATION SENSOR (RIGHT SIDE OF CARGO AREA)
SEAT VENTILATION CONTROL UNIT (UNDER CENTER CONSOLE)
TECH FUSE 1
TECH RELAY
TRANSCEIVER F-CAN
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDER-HOOD CONTROL FUSE/RELAY BLOCK BOX (RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Electronic suspension circuit (2 of 2) -> MILLIMETER WAVE RADAR UNIT (FRONT OF
