Acura MDX II facelift (2010-2013) line out + Wiring diagrams
This page contains all the electrical diagrams for the component. line out +, in which he is found in the car Acura MDX II facelift (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram line out + (1 of 5)
AM/FM ANTENNA
AM/FM ANTENNA AMPLIFIER (CENTER REAR OF ROOF)
AM/FM ANTENNA LEAD CONNECTOR
AUDIO R- AUDIO L-
AUDIO UNIT
AUXILIARY JACK ASSEMBLY
B-CAN
B-CAN HVAC
BLK WIRE
BLU WIRE
BRN WIRE
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
DET
DOOR SPEAKER
FRONT PASSENGER'S
FUSE 32
FUSE 5
FUSE 8
GANET-BUS (+) GANET-BUS (-)
GANET-BUS SHLD AUDIO SHLD AUDIO R (+) AUDIO L (+)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
K LINE
L CH-
LINE OUT +
LT BLU WIRE
LT GRN WIRE
MAIN UNDER-HOOD FUSE/RELAY BOX (LEFT FRONT OF ENGINE COMPT)
MICU
NAVIGATION SYSTEM
NCA WIRE
NET BUS (+) NET BUS (-) GND
NET BUS SHLD
ORG/ WIRE
PPL
PPL LINE OUT (-) LINE OUT SHLD
R CH L CH DET
R CH-
RED WIRE
RIGHT TWEETER
SATELLITE SIGNAL ANTENNA
SHLD
SIG GND
SIG GND SHLD
TER-SAT GND SH
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
WHT WIRE
XM ANTENNA
XM RECEIVER (RIGHT SIDE OF CARGO AREA)
Go to component -> Base radio circuit (1 of 2) -> LINE OUT +
