Acura MDX II facelift (2010-2013) light memory switch driving position Wiring diagram
This page shows the only wiring diagram for the component.light memory switch driving position, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light memory switch driving position (1 of 1)
1 BUTTON POSITION
8 5 2 3 6 PPL
BLK WIRE
BLU WIRE
BRN WIRE
DOWN
DRIVER'S MPCS UNIT (IN DRIVER'S DOOR)
DRIVING POSITION MEMORY SWITCH
FUSE 15
FUSE 21
FUSE 28
FUSE 7
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LIGHT MEMORY SWITCH DRIVING POSITION
LT BLU WIRE
LT GRN WIRE
MEMO BUTTON
ORG/ WIRE
PNK TEM+ TIM- TIM+ WIRE
PNK WIRE
POSITION 1 IND
POSITION 2 BUTTON
POSITION 2 IND
POWER TELESCOPIC STEERING MOTOR/ POSITION SENSOR
POWER TILT STEERING MOTOR/ POSITION SENSOR
POWER TILT/ TELESCOPIC STEERING CONTROL UNIT (UNDER LEFT SIDE OF DASH)
POWER TILT/ TELESCOPIC STEERING SWITCH
PPL
PPL PPL
PULL
PUSH
RED WIRE
SG (BEHIND RIGHT SIDE OF DASH)
SW BAT SEG
SWG UART TISB TESB PPL COMPUTER DATA LINES SYSTEM
TELESCOPIC SWITCH
TEM
TILT SWITCH
TISA TESA
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
VBU SVCC PPL
WHT WIRE
YEL WIRE
Go to component -> Memory power tilt & power telescopic circuit -> LIGHT MEMORY SWITCH DRIVING POSITION
