Acura MDX II facelift (2010-2013) indicators on Wiring diagrams
This page contains all the electrical diagrams for the component. indicators on, in which he is found in the car Acura MDX II facelift (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram indicators on (1 of 2)
BLK WIRE
BRN WIRE
DRIVER'S DRIVER'S SEAT BACK HEATER SEAT CUSHION HEATER
DRIVER'S SEAT HEATER
DRIVER'S SEAT HEATER SWITCH
FRONT PASSEN- GER'S SEAT CUSHION HEATER
FRONT PASSEN- GER'S SEAT HEATER
FRONT PASSEN- GER'S SEAT HEATER SWITCH
FRONT SEAT HEATER RELAY
FUSE 30
FUSE 4
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HI LO
HOT AT ALL TIMES
HOT IN ON
INDICATORS ON
LIGHT
LO HI
LO HI HI LO
LO LO HI HI
LT BLU WIRE
LT GRN WIRE
ON INDICATORS
PNK PNK WIRE
RED WIRE
SWITCH
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
WHT/BLU WIRE
YEL WIRE
Go to component -> Front heated seats circuit -> INDICATORS ON
Wiring diagram indicators on (2 of 2)
AUXILIARY UNDER-DASH RELAY BLOCK A (UNDER LEFT SIDE OF DASH)
BLK WIRE
BRN WIRE
FUSE 14
FUSE 30
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HI LO
HI LO HI
HOT AT ALL TIMES
HOT IN ON
INDICATORS
INDICATORS ON
LEFT SECOND ROW LO HI SEAT HEATER SWITCH LO
LEFT SECOND ROW SEAT BACK HEATER
LEFT SECOND ROW SEAT CUSHION HEATER
LEFT SECOND ROW SEAT HEATER
LIGHT
LO HI HI LO
LT BLU WIRE
LT GRN WIRE
MAIN UNDER-HOOD FUSE/RELAY BOX (LEFT FRONT OF ENGINE COMPT)
PNK WIRE
RED WIRE
RIGHT SECOND ROW SEAT BACK HEATER
RIGHT SECOND ROW SEAT HEATER
RIGHT SECOND ROW SEAT HEATER SWITCH
RIGHT SECOND ROW TH SEAT CUSHION HEATER CB
SECOND ROW SEAT HEATER RELAY
SWITCH
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
WHT/BLU WIRE
YEL WIRE
Go to component -> Rear heated seats circuit -> INDICATORS ON
