Acura MDX II facelift (2010-2013) hid unit Wiring diagram
This page shows the only wiring diagram for the component.hid unit, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hid unit (1 of 1)
BATTERY
BATTERY SENSOR
BLK WIRE
BRN WIRE
CABLE REEL (BEHIND STEERING COLUMN COVER)
CARGO AREA FUEL FILL DOOR OPENER ACCESSORY POWER SOCKET SOLENOID
DASH LIGHTS BRIGHTNESS CONTROLLER
ENGINE MOUNT BRACKET
FUEL PUMP CONTROL MODULE
GAUGE CONTROL MODULE
GRN/ WHT WIRE
HID UNIT
LEFT FRONT LEFT PARKING FRONT TURN LEFT FOG LIGHT SIGNAL LIGHT LIGHT
LEFT FRONT SIDE LEFT LEFT MARKER LIGHT DRL HEADLIGHT (HIGH BEAM)
LEFT HID UNIT
MOONROOF CONTROL UNIT/MOTOR
PADDLE
PADDLE PADDLE SHIFTERS SHIFTER + SHIFTER - (UPSHIFT (DOWNSHIFT SWITCH) SWITCH)
RADIATOR FAN MOTOR
REAR FUSE/RELAY MICU BOX (LEFT SIDE OF CARGO AREA)
RIGHT DRL
RIGHT FOG LIGHT
RIGHT FRONT PARKING LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT (HIGH BEAM)
RIGHT HID UNIT
RIGHT REAR RIGHT REAR DOOR LOCK POWER ACTUATOR/ WINDOW KNOB SWITCH SWITCH
SECURITY HOOD SWITCH
SH-AWD RELAY
SRS UNIT
TRAILER ELECTRIC BRAKE CONNECTOR
TRANSMISSION HOUSING)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) FRONT SEAT HEATER RELAY
USA: BASE, CANADA
USA: EXCEPT BASE
VSA MODULATOR CONTROL UNIT
WASHER FLUID LEVEL SWITCH
WHT GRN/ WIRE
WHT/ BLU WIRE
Go to component -> Ground distribution circuit (1 of 5) -> HID UNIT
