Acura MDX II facelift (2010-2013) front seat micu heater relay Wiring diagram
This page shows the only wiring diagram for the component.front seat micu heater relay, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front seat micu heater relay (1 of 1)
A/C
ABS/VSA FUSE
ALTERNATOR TO MAIN UNDER-HOOD FUSE BOX (DIAGRAM 3 OF 6)
AUXILIARY UNDER-DASH RELAY BLOCK B (UNDER LEFT SIDE OF DASH)
BATTERY
BATTERY SENSOR
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S LUMBAR SUPPORT SWITCH
DRIVER'S POWER SEAT CONTROL UNIT
FRONT SEAT MICU HEATER RELAY
FUSE
FUSE 1
FUSE 10
FUSE 13
FUSE 14 FUSE 17
FUSE 16 FUSE 15 FUSE 12
FUSE 2
FUSE 2 FUSE 1 FUSE 3
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
HAZARD WARNING SWITCH/ FRONT PASSENGER'S AIR BAG CUTOFF INDICATOR
INVERTER
LT BLU WIRE
LUMBAR SUPPORT SHORT PIN
MAIN FUSE
MOONROOF CONTROL UNIT/ MOTOR
MULTI FUSE 1
MULTI FUSE 2
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER OUTLET AC-
POWER SUBWOOFER TILT/ (EXCEPT TELESCOPIC BASE) STEERING CONTROL UNIT
POWER SUPPLY CIRCUIT
PPL
REAR FUSE/ RELAY BOX (LEFT SIDE OF CARGO AREA) FUSE 4
RED WIRE
RR BLOWER FUSE
SH-AWD FUSE
SH-AWD RELAY
STARTER
STARTER SOLENOID
STEREO AMPLIFIER TO
TO ELD (DIAGRAM 2 OF 6)
TO FUSE 12 (DIAGRAM 2 OF 6)
TO FUSE 14 (DIAGRAM 3 OF 6)
TPMS FRONT PASSENGER'S CONTROL POWER SEAT UNIT ADJUSTMENT SWITCH
TRAILER CHARGE RELAY
TRAILER LIGHTING CONTROL UNIT
TRAILER LIGHTING RELAY
TRAILER MAIN FUSE
TURN SIGNAL/ HAZARD RELAY
VSA MODULATOR CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 6) -> FRONT SEAT MICU HEATER RELAY
