Acura MDX II facelift (2010-2013) front climate passenger's control mpcs unit unit Wiring diagram
This page shows the only wiring diagram for the component.front climate passenger's control mpcs unit unit, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front climate passenger's control mpcs unit unit (1 of 1)
+B BACKUP MICU
ACCESSORY POWER SOCKET RELAY
ACURA EXCEPT ACURA ACCESSORY ACCESSORY
BASE, USA: TECHNOLOGY, ADVANCE PACKAGE
BLK WIRE
CENTER INFORMATION DISPLAY (BASE)
CONTROL BLOCK
DLC
DRIVER'S MPCS UNIT
DRIVER'S POWER SEAT CONTROL UNIT
FROM FUSE 20 (DIAGRAM 5 OF 6)
FROM FUSE 32 (DIAGRAM 4 OF 6)
FROM FUSE 6 (DIAGRAM 3 OF 6)
FRONT ACCESSORY POWER SOCKET CIGARETTE LIGHTER
FRONT CLIMATE PASSENGER'S CONTROL MPCS UNIT UNIT
FRONT REAR WASHER WASHER MOTOR MOTOR RELAY RELAY
FUSE 22
FUSE 29
FUSE 31
FUSE 7
FUSE 9
HFL-NAVIGATION MICROPHONE (EXCEPT BASE)
IMMOBILIZER POWER TILT/ KEYLESS TELESCOPIC STEERING CONTROL UNIT CONTROL UNIT
INTERMITTENT WIPER RELAY
MICU
NAVIGATION DISPLAY UNIT (EXCEPT BASE)
ORG/ WIRE
REAR ACCESSORY POWER SOCKET
REAR FUSE/ RELAY BOX (LEFT SIDE OF CARGO AREA)
REAR FUSE/ STEERING RELAY BOX ANGLE (LEFT SIDE SENSOR OF CARGO AREA)
RED WIRE
SRS UNIT
UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
VSA MODULATOR CONTROL UNIT
WHT WIRE
WINDSHIELD WIPER HIGH RELAY
WIPER/ GAUGE WASHER CONTROL MODULE SWITCH
YAW RATE, LATERAL, LONGITUDINAL ACCELERATION SENSOR
YEL WIRE
Go to component -> Power distribution circuit (6 of 6) -> FRONT CLIMATE PASSENGER'S CONTROL MPCS UNIT UNIT
