Acura MDX II facelift (2010-2013) combination switch intvol control unit Wiring diagram
This page shows the only wiring diagram for the component.combination switch intvol control unit, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram combination switch intvol control unit (1 of 1)
+B INT, LO
B-CAN
BLK WIRE
BLU WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
BUMPER, ON WASHER RESERVOIR)
CAN HI, LO
COMBINATION SWITCH INTVOL CONTROL UNIT
CONTROL BLOCK
CONTROL CIRCUIT
FRONT WASHER MOTOR RELAY
FUSE 11
FUSE 21
FUSE 31
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INT LOW OFF HIGH MIST
INT OFF LOW MIST HIGH
INTERMITTENT DWELL TIME CONTROLLER
INTERMITTENT WIPER RELAY
J/C
LOW HIGH
LT GRN WIRE
MICU
MIST
OF COWL COVER)
ORG/ WIRE
PARK
PNK WIRE
POWER DISTRIBUTION SYSTEM
REAR WASHER MOTOR RELAY
RED WIRE
RUN WIRE
UNDER-DASH FUSE/RELAY BOX (BEHIND
VBU
WASHER
WASHER FLUID LEVEL SWITCH (BEHIND RIGHT SIDE OF FRONT
WHT WIRE
WINDSHIELD WASHER MOTOR (BEHIND RIGHT SIDE OF FRONT BUMPER, ON WASHER RESERVOIR)
WINDSHIELD WINDSHIELD WASHER SWITCH WIPER OFF SWITCH WASH
WINDSHIELD WIPER HIGH RELAY
WINDSHIELD WIPER MOTOR (UNDER LEFT SIDE
WIPER/ WASHER SWITCH
YEL WIRE
Go to component -> Front wiper/washer circuit -> COMBINATION SWITCH INTVOL CONTROL UNIT
