Acura MDX II facelift (2010-2013) combination switch control unit rr wsh gnd Wiring diagram
This page shows the only wiring diagram for the component.combination switch control unit rr wsh gnd, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram combination switch control unit rr wsh gnd (1 of 1)
B-CAN
BLK WIRE
BLU WIRE
COMBINATION SWITCH CONTROL UNIT RR WSH GND
CONTROL BLOCK
FRONT WASHER MOTOR RELAY
FUSE 21
FUSE 31
FUSE 7
HOT AT ALL TIMES
HOT IN ON OR START
J/C
LT GRN WIRE
MICU
OFF RR WIP RR WASH
ORG/ WIRE
PARK
POWER DISTRIBUTION SYSTEM
REAR FUSE/ RELAY BOX (LEFT SIDE OF CARGO AREA) MICU +B BACK UP RR WIPER AS
REAR WASHER MOTOR RELAY
REAR WINDOW WIPER MOTOR
REAR WINDOW WIPER/ WASHER SWITCH RR WIP OFF RR WASH RR WASH
RED WIRE
RR WASH
RR WIPER LO
RR WP
RUN WIRE
UNDER-DASH FUSE/RELAY BOX (BEHIND
VBU
WHT WIRE
WINDSHIELD WASHER MOTOR (BEHIND RIGHT SIDE OF FRONT BUMPER, ON WASHER RESERVOIR)
WIPER/ WASHER SWITCH
YEL WIRE
Go to component -> Rear wiper/washer circuit -> COMBINATION SWITCH CONTROL UNIT RR WSH GND
