Acura MDX II facelift (2010-2013) bkswnc bksw atpfwd nc Wiring diagram
This page shows the only wiring diagram for the component.bkswnc bksw atpfwd nc, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bkswnc bksw atpfwd nc (1 of 1)
ACC IND (AMBER)
ACC IND (GREEN)
APP SENSOR (UNDER LEFT SIDE OF DASH)
APSB
BKSWNC BKSW ATPFWD NC
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
CANH CANL MRLY ETCSRLY
CMBS IND
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUITS
CONTROLLER
ETCSM- ETCSM+
FAST
FUSE 21
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
J/C
LT GRN WIRE
NETWORK AREA
ORG/ WIRE
OUTPUT SHAFT (COUNTERSHAFT) SPEED SENSOR (ON TRANSMISSION HOUSING)
PCM (RIGHT FRONT OF ENGINE COMPT)
PPL
PPL APSA
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
THROTTLE ACTUATOR
TP SENSOR
TP SENSOR/THROTTLE ACTUATOR (LEFT SIDE OF ENGINE)
TPSA VCCS TPSB
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Adaptive cruise control circuit (1 of 3) -> BKSWNC BKSW ATPFWD NC
