Acura MDX II facelift (2010-2013) backup sensor in line fuse Wiring diagram
This page shows the only wiring diagram for the component.backup sensor in line fuse, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backup sensor in line fuse (1 of 1)
B/SENS L B/SENS R C/SENS BUZZER
BACKUP SENSOR BEEPER
BACKUP SENSOR CONTROL UNIT (LEFT REAR OF CARGO AREA)
BACKUP SENSOR IN LINE FUSE
BLK WIRE
BLU WIRE
BRN WIRE
FUSE 21
GRN WIRE
GRY WIRE
HOT IN ON OR START
LEFT CENTER BACKUP SENSOR (BEHIND LEFT SIDE OF REAR BUMPER)
LEFT CORNER BACKUP SENSOR (LEFT SIDE OF REAR BUMPER)
MICU BACK LT
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT CENTER BACKUP SENSOR (BEHIND RIGHT SIDE OF REAR BUMPER)
RIGHT CORNER BACKUP SENSOR (RIGHT SIDE OF REAR BUMPER)
SENS- GND SENS+ C/SENS L C/SENS R
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Parking assistant circuit -> BACKUP SENSOR IN LINE FUSE
