Acura MDX II facelift (2010-2013) a/t clutch pressure control solenoid valve c Wiring diagram
This page shows the only wiring diagram for the component.a/t clutch pressure control solenoid valve c, which is found in the car Acura MDX II facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/t clutch pressure control solenoid valve c (1 of 1)
A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE A
A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE C
A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE D
A/T CLUTCH PRESSURE SHIFT CONTROL CONTROL SOLENOID SOLENOID VALVE B VALVE B
BLK WIRE
BRAIDED WIRE
BRN/YEL WIRE
CKP SENSOR
DRIVER SEAT DRIVER'S POSITION SEAT BELT SENSOR BUCKLE SWITCH
DRIVER'S DRIVER'S SEAT BACK SEAT FAN CUSHION FAN HEATER MOTOR
DRIVER'S LUMBAR SUPPORT SWITCH
DRIVER'S POWER SEAT CONTROL UNIT
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT HEATER
DRIVER'S SEAT- BACK HEATER
EGR VALVE/ EGR VALVE POSITION SENSOR
FRONT A/F
FRONT SECONDARY
GRN WIRE
GRN/YEL WIRE
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
IGNITION IGNITION COIL 2 COIL 1
J/C
KNOCK SENSOR SHIELD
LINE PRESSURE SOLENOID IGNITION VALVE A COIL 3
PCM
REAR A/F SENSOR
REAR SECONDARY
RIGHT SECOND ROW SEAT HEATER
ROCKER ARM OIL PRESSURE CMP SENSOR SWITCH
SECONDARY
SHIELD
SHIELDS
SHIFT CONTROL SOLENOID VALVE A
SHIFT CONTROL SOLENOID VALVE C
TRANSMISSION RANGE SWITCH
USA: ADVANCE, ADVANCE/ENTERTAINMENT; CANADA: ELITE
YEL WIRE
Go to component -> Ground distribution circuit (3 of 5) -> A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE C
